Transmitter Specifications

The technical specifications for the transmitters that appear in this appendix are listed below. All transmitters are
available in 868, or 433MHz (optional) FM frequencies.
El-4755 PIR
Frequency: 868* or 433MHz
Power: 3.6VDC AA Lithium Battery (x 2)
Current Consumption: 200mA (capture with flash), 42µA (standby)
Pyroelectric Sensor: Dual Element
Maximum Coverage: 14 x 14m
Pulse Count: 1 or 2
LED Indicator: Selectable
Digital Adaptive Temperature Compensation
RFI Immunity: According to EN 50130-4
Operating Temperature: 0 to 60°C
Fire Protection: ABS Plastic Housing
Dimensions: 110 x 62 x 50mm
* Complies with EN-50131 2-2 Grade 2 Class II, Power Supply Type C
El-4755PI PIR
Frequency: 868* or 433MHz
Power: 3.6VDC AA Lithium Battery (x 2)
Current Consumption: 200mA (capture with flash), 42µA (standby)
Pyroelectric Sensor: Dual Element
Maximum Coverage: 11 x 11m
Pulse Count: 1 or 2
LED Indicator: Selectable
Digital Adaptive Temperature Compensation
RFI Immunity: According to EN 50130-4
Operating Temperature: 0 to 60°C
Fire Protection: ABS Plastic Housing
Dimensions: 110 x 62 x 50mm
* Complies with EN-50131 2-2 Grade 2 Class II, Power Supply Type C
El-4745 PIR
Frequency: 868* or 433MHz
Power: 3.6V ½ AA Lithium Battery (Optional x 2)
Current Consumption: 30mA (transmission), 35µA (standby)
Pyroelectric Sensor: Dual Element
Maximum Coverage: 14 x 14m
Pulse Count: 1 or 2
LED Indicator: Selectable
Digital Adaptive Temperature Compensation
RFI Immunity: According to EN 50130-4
Operating Temperature: 0 to 60°C
Fire Protection: ABS Plastic Housing
Dimensions: 110 x 62 x 50mm
* Complies with EN-50131 2-2 Grade 2 Class II, Power Supply Type C
El-4745PI PIR
Frequency: 868* or 433MHz
Power: 3.6V ½ AA Lithium Battery (Optional x 2)
Current Consumption: 30mA (transmission), 35µA (standby)
Pyroelectric Sensor: Dual Element
Maximum Coverage: 11 x 11m
Pulse Count: 1 or 2
LED Indicator: Selectable
Digital Adaptive Temperature Compensation
RFI Immunity: According to EN 50130-4
Operating Temperature: 0 to 60°C
Fire Protection: ABS Plastic Housing
Dimensions: 110 x 62 x 50mm
* Complies with EN-50131 2-2 Grade 2 Class II, Power Supply Type C
120
Appendix B: Transmitter Installation
EL-4601DZ Magnetic Contact/ Universal Transmitter
Frequency: 868* or 433MHz
Power: 3.6VDC ½ AA Lithium Battery
Current Consumption: 25mA (transmission), 10µA (standby)
RFI Immunity: According to EN 50130-4
Operating Temperature: 0-60°C
*Complies with EN-50131 2-6 Grade 2 Class II Power Supply Type C
EL-4602 Universal Transmitter
Frequency: 868* or 433MHz
Power: 3.6VDC ½ AA Lithium Battery
Current Consumption: 25mA (transmission), 10µA (standby)
RFI Immunity: According to EN 50130-4
Operating Temperature: 0-60°C
*Complies with EN-50131 2-6 Grade 2 Class II Power Supply Type C
EL-4607 Vibration Detector
Frequency: 868* or 433MHz
Power: 3.6VDC ½ AA Lithium Battery
Current Consumption: 25mA (transmission), 10µA (standby)
RFI Immunity: According to EN 50130-4
Alarm Delay During Normal Operation: Approx. 4 minutes
Operating Temperature: 0-60°C
*Complies with EN-50131 2-6 Grade 2 Class II Power Supply Type C
EL-4703 Smoke Detector
Frequency : 868* or 433MHz,
Power: 2xCR123 3V Lithium battery
Average Standby Current: 0.04mA
Test Current: 55mA
Alarm Current: 55mA
Peak Trouble Pulse Current: 4.73mA
Peak Pulse Current: 0.074mA
Alarm Sound Level: Exceeds 85dB at 3m (10 feet)
Operating Temperature: -10°C to 40°C (14°F - 104°F)
Dimensions: Diameter: 148 x 53mm
*Complies with EN-50131 2-6 Grade 2 Class II Power Supply Type C
EL-4714 Keyfob
Frequency: 868* or 433MHz
Power: 3V Lithium Battery, Type CR2032
Current Consumption: 16mA (transmission), 0.2µA (standby)
RFI Immunity: According to EN 50130-4
Operating Temperature: 0-60°C
*Complies with EN- Grade 2 Class II Power Supply Type C
EL-4611M/P Keyfob
Frequency: 868* or 433MHz
Power: 3V Lithium Battery, Type CR2032
Current Consumption: 16mA (transmission), 0.2µA (standby)
RFI Immunity: According to EN 50130-4
Operating Temperature: 0-60°C
*Complies with EN- Grade 2 Class II Power Supply Type C
