PIR Detectors (EL-4745/EL-4745PI)

The EL-4745 and EL-4745PI are intelligent 2-Way wireless PIR detectors designed for use with the iConnect
System. All of these detectors implement a feature to combat the problem of multiple transmissions, which drastically
reduce the life of the batteries. After each transmission, there is a four-minute delay during which further transmissions
will not be sent. When batteries need replacing, the detector sends a low battery indication to the Control System.
Detectors that meet the EN-50131 standard, have a three-minute delay between transmissions.
The EL-4745PI is designed for installations prone to nuisance alarms caused by pets or small animals.
