11.3. GPRS Network Parameters

The following parameters, required to program your GPRS connection, should be provided by the cellular provider.
11.3.1. APN
To edit the APN name of your GPRS connection:
1. From the Programming menu, select Communications, Internet, GPRS Options, APN [95761].
2. Enter the APN name provided by the cellular provider. Use the "1" key to enter ".",
to delete one character at a time.
11.3.2. User Name
To edit the User name of your GPRS connection (optional setting provided by the cellular provider):
1. From the Programming menu, select Communications, Internet, GPRS Options, User Name [95762].
2. Enter the User Name provided by the cellular provider. Use the "1" key to enter ".",
to delete one character at a time.
3. Press '√ʹ when you have finished editing.
11.3.3. Password
To edit the Password of your GPRS connection (optional setting provided by the cellular provider):
1. From the Programming menu, select Communications, Internet, GPRS Options, Password [95763].
2. Enter the Password provided by the cellular provider. Use the "1" key to enter ".",
delete one character at a time.
11.3.4. GPRS Write TMO
To edit the GPRS Write TMO of your GPRS connection:
1. From the Programming menu, select Communications, Internet, GPRS Options, GPRS Write TMO [95764].
2. Enter the GPRS Write TMO (015 -255 seconds). Press '√ʹ when finished.

11.4. LAN Network Parameters

The following options concern the configuration of the Ethernet. All of the information required for programming these
options should be provided by the network administrator.
There are two methods of programming the IP settings:
• Automatic IP settings (DHCP) – when using a DHCP server, the server provides all of the configuration
settings automatically.
• Manual IP settings – you must enter the relevant IP addresses, Gateway and Subnet Mask, taking into
consideration your router settings.
11.4.1. LAN IP Address
To edit the LAN IP address:
1. From the Programming menu, select Communications, Internet, LAN Options, LAN IP Address [95771].
2. Enter an IP address. Press the
at a time.
When you choose to use DHCP, set the IP address and Gateway values to "0", and
the subnet mask to 255.255.255.000 (or another value according to your router's
settings); if not, insert the IP Address, Subnet Mask, and Gateway. Press '√ʹ when
you have finished editing.
11.4.2. Subnet Mask
To edit the subnet mask:
1. From the Programming menu, select Communications, Internet, LAN Options, Subnet Mask [95772].
2. Enter the Subnet Mask. Press the
character at a time.
68
key as many times as necessary to select "." and the
key as many times as necessary to select "." and the
11 Internet Options
key to insert and the
key to insert and the
key to insert and the key to
key to delete one character
key to delete one
