Testing the Siren Strobe
Once the siren strobe has been registered test the unit according to the following testing procedure:
To perform a siren strobe test
1. Go to the main menu and select [7]>[0]>[3]>[1] (Service> Tests> WL Siren Test).
2. Select a siren from the list (1-4) and press '√ʹ. The selected siren is sounded briefly.
Deleting the Siren Strobe
To delete a siren strobe from the system:
1. Set the system to Delete mode.
2. Go to the main menu and select [9]>[1]>[5] (Programming > Devices > Siren).
3. Press >5, and press '√ʹ. Upon the 'OK' confirmation request, press ʹ√ʹ
4. Open the siren strobe and take out the batteries.
5. Press the tamper switch. While the tamper switch is being pressed insert the batteries. Within five seconds open the
tamper and close it again.
