4 Advanced System Operation
4.7.9. Audio Volume
To adjust the sensitivity of the microphone and the volume of the speaker:
1. Establish a two-way audio connection – see 5.1.4 Telecontrol Call Procedure.
2. From the Service menu, select Audio Volume [705].
3. Using the arrow keys on the Front Panel keypad, adjust the setting according to the following table.
Table 4-3: Voice Level Adjustment
Key...
1
4
3
6
4. Press '√ʹ; the new se ings are stored in the memory.
4.7.10. GSM Signal Strength
You can measure the GSM signal strength. This function enables you to calculate the optimal location to install the
Control System with the Cellular Communication Module.
To view the GSM signal strength reading:
• From the Service menu, select GSM Signal [706]; the signal strength of the cellular network is displayed.
Table 4-4: GSM Signal Level
Reading
8-9
5-7
Less than 5
In severe cases of low GSM signal consider using external GSM antenna.
4.7.11. Display Version
To display the system's software and hardware versions:
From the Service menu, select Version [707]; the hardware (HW) and software (SW) versions are displayed.
4.7.12. Enable Programming
The Enable Programming command enables a user with Master code authorization to grant access to system
programming. This feature is relevant only if the Installer Access and/or the RP Access options are programmed as
"User Initiated" – see p. 52, 9.14 Installer Access and p. 59, RP Access Options.
To grant access to the installer or Remote Programmer:
From the Service menu, select Enable Prog. [708]; a 30-minute time window is opened during which the Installer Code
is valid or RP communication may be established.
4.7.13. Global Chime
The Chime feature causes the Control System's built-in siren to ring when specific zones are triggered. Using the Global
Chime option, you can enable or disable this feature for all zones that are defined as Chime enabled – see p.38, 7.3.5
Chime.
To enable or disable Global Chime:
1. From the Service menu, select Global Chime [709].
2. Select either Enabled or Disabled.
3. Press '√ʹ when the desired setting is displayed.
Though the Service menu is accessible to the Master and Installer only, Global Chime can
also be accessed via a convenient shortcut without needing to enter a valid user code. To
access the Global Chime option from Standby mode, press
iConnect Installation Manual
Function
Increases microphone sensitivity
Reduces microphone sensitivity
Increases speaker volume
Reduces speaker volume
Meaning
Reception is good
Reception is acceptable
Reception is unacceptable
then .
