Figure 4.2 shows the detailed event log entry for a Fire alarm on November 14
The event was successfully reported to the central station.
4.6.1: Event Log Authorization Levels
Every event that occurs is recorded in the event log. However, certain events are
intended for the installer only. Those events include various service messages that are of
little interest to the regular user. The View Log function requires you to enter either the
Master or Installer code. The events that are displayed depend on which code you use to
enter the log – see Appendix C: Event Table.
4.6.2: Clearing the Event Log
The Clear Log function erases all events from the log. After performing this function, a
Clear Log event is recorded in the log. The Clear Log function is accessible using the
Installer code only.
To clear the event log:
1. From the Event Log menu, select Clear Log [62]; the OK? confirmation
message is displayed.
2. Press ; the log is cleared.
For certain versions of the infinite prime software, the Clear Log function may be disabled.

4.7: Service Menu

The Service menu is accessible using either the Installer or Master code. This menu
includes various functions that enable you to test the system effectively.
4.7.1: Set Time & Date
The time and date are used to time stamp events in the event log. Additionally the time is
also displayed on the LCD display.
To set the time:
1. From the Service menu, select Set Time/Date, Set Time [7011].
2. Enter the current time.
3. Press ; the time is modified.
To set the date:
1. From the Service menu, select Set Time/Date, Set Date [7012].
2. Enter the current date.
3. Press ; the date is modified.
The format of the time and date is defined in the System Options – see 9.6.3: Time/Date
Format. If you are setting the time in 12hr format, use the key to toggle between AM and PM.
4.7.2: Message Center
The infinite prime Message Center is designed to allow the user to record a short
message that may be played back later by another user. After a message is recorded,
Message Waiting is displayed on the LCD until the message is played back.
To play back a recorded message:
•
From the Service menu, select Messages, Play Message [7021].
-33-
th
2003.
