Chapter 4—Editing in Direct Mode

Example

Assuming that...
• the printer has been set up for the application (see
• the length of the label and the gap has been determined by printing a
Test Label (see
• and the graphic used in the example has been downloaded to the
printer as described on page
...we will now print two copies of a label which we will edit in the Direct
Mode. The label will look like the example on
The label can be printed as many times as you want, as long as it still is
stored in the image buffer. Once replaced, it cannot be retrieved. It also
implies that counters and variables cannot be used.
Command
↵
N↵
X0,0,4,752,584↵
LO0,144,752,4↵
LO440,232,4,160↵
A40,400,1,1,1,1,N,"Made in Sweden"↵
A24,160,0,5,1,1,R,"EASYCODER"↵
A24,250,0,4,1,1,N,"MODEL: 501SA"↵
A472,312,0,4,1,1,N,"Checked by: Dan"↵
A24,312,0,4,1,1,N,"SERIAL#: 000001"↵
B280,440,0,1,2,3,96,B,"S 000001"↵
GG24,12,"LOGO"↵
P2↵
1
/. The Intermec logotype is not included in the software package and
is only included in the example to demonstrate how to print a graphics
fi eld. You can substitute it with any graphics of approximately the same
size. If you fi nd it diffi cult to download graphics, you could omit the
command from the example until you have become more familiar with
the concept.
18 Intermec EasyCoder ESim v4.00—Programmer's Reference Manual
page 2),
68 (GM
page
1
command ),
page 20.
Explanation
CR/LF to start command structure
Clear image memory
Draw a box
Draw a line
Draw a line
Write a 90° text line of fi xed data
Write a text line of fi xed data
Write a text line of fi xed data
Write a text line of fi xed data
Write a text line of fi xed data
Write barcode representing fi xed data
Write a graphic from graphics memory
Print command to image buffer; Print
2 copies
14),
1
GG
