Chapter 7—Commands
Q – Set Form Length (Black Mark), cont.
On this tag, the black marks are printed on the perforation in a
Examples
203.2 dpi (8 dots/mm) printer:
p = 31.0 mm (248 dots)
1
p = 7.0 mm (56 dots)
2
p = 0.5 mm (4 dots)
3
p
1
The Q command would be: Q248,B56+4↵
On the tag below, the black marks are printed between the
perforations. The printer has a 203.2 dpi (8 dots/mm) printhead.
p = 31.0 mm (248 dots)
1
p = 7.0 mm (56 dots)
2
p = 17 mm (136 dots)
3
p
1
The Q command would be: Q248,B56-136 ↵
92 Intermec EasyCoder ESim v4.00—Programmer's Reference Manual
Perforation
p
2
p
3
Perforation
p
2
p
3
