Appendix A — Error-Handling

Error Replies Table

Error Description
Code Type
00 No Error
01 A Syntax Error
02 B Object exceeds image buff er
border
03 A Data Length error
04 A Insuffi cient Memory to Store
Data
05 A Memory Confi guration Error
Out of media, marked with "P"
nnn = numbers of remaining
labels
07 C
Out of ribbon, marked with "R"
nnn = numbers of remaining
labels
08 A Form or image name duplicate
09 A Form or image not found
11 D Print Head Up (Cover Open)
13 E LTS-detection waiting, peel
pause
16 A No form was retrieved before
"?<CRLF> " was entered.
50 A Does not fi t in area specifi ed
51 A Data length too long
61 D High Motor temp
62 D High Print Head temp
71 F Wait after Default Setup
72 F Flashing not completed
73 F Download error
81 B Cutter Jammed or Not Installed
89 G Dump mode (after auto
detection)
1
if command USE has been preceded.
144 Intermec EasyCoder ESim v4.00—Programmer's Reference Manual
Error Response depending on cmd US/UN
command US:
reporting on
LED Serial
GRN -
RED <NAK>01[XOFF]
ORA <NAK>02[XOFF]
RED <NAK>03[XOFF]
RED <NAK>04[XOFF]
RED <NAK>05[XOFF]
RED <NAK>07Pnnn[XOFF]
RED <NAK>07Rnnn[XOFF]
RED <NAK>08[XOFF]
RED <NAK>09[XOFF]
RED <NAK>11[XOFF]
1
- <NAK>13[XOFF]
RED <NAK>16[XOFF]
RED <NAK>50[XOFF]
RED <NAK>51[XOFF]
BLNK <NAK>61[XOFF]
RED
BLNK <NAK>62[XOFF]
RED
GRN -
RED <NAK>72[XOFF]
RED <NAK>73[XOFF]
BLNK <NAK>81[XOFF]
RED
GRN <NAK>89[XOFF]
Response
at cmd
command UN:
^ee
reporting off
LED Serial
GRN - 00<CRLF>
GRN - 01<CRLF>
ORA [XOFF] 02<CRLF>
GRN - 03<CRLF>
GRN - 04<CRLF>
GRN - 05<CRLF>
RED [XOFF] 07<CRLF>
RED [XOFF] 07<CRLF>
GRN - 08<CRLF>
GRN - 09<CRLF>
RED [XOFF] 11<CRLF>
- - 13<CRLF>
GRN - 16<CRLF>
GRN - 50<CRLF>
GRN - 51<CRLF>
BLNK [XOFF] 61<CRLF>
RED
BLNK [XOFF] 62<CRLF>
RED
GRN [XOFF] 71<CRLF>
RED [XOFF] 72<CRLF>
RED [XOFF] 73<CRLF>
BLNK [XOFF] 81<CRLF>
RED
GRN - 89<CRLF>
