Chapter 5—Editing in Form Edit Mode
Draw a Box and two Lines
Start to draw the surrounding box using the X command and then draw
the two lines using the LO command.
Command
X0,0,4,752,584↵
LO0,144,752,4↵
LO440,232,4,160↵
Place a Text Line with Fixed Data
Enter a 90° rotated text line containing the fi xed data "Made in Sweden"
in text size 1. The quotation marks enclosing the fi xed data will not be
printed. The text size (1) is the smallest resident font in the printer.
Command
A40,400,1,1,1,1,N,"Made in Sweden"↵
Place a Variable Text
The next line is a text line, using text size 5 in reverse and prints the
variable V00. The data printed in this fi eld must be sent to the printer at
the time of form retrieval.
Command
A24,160,0,5,1,1,R,V00 ↵
Place a Combination of Fixed Data and a Variable
The following two command lines consist of a combination of fi xed data
enclosed in quotation marks and variable data.
Command
A24,250,0,4,1,1,N,"MODEL: "V01↵
A472,312,0,4,1,1,N,"Checked by: "V02↵ Text line, fi xed data + 3:rd variable
22 Intermec EasyCoder ESim v4.00—Programmer's Reference Manual
Explanation
Draw a box
Draw a black line
Draw a black line
Explanation
90 degree. text line, fi xed data
Explanation
Write a text line, 1:st variable
Explanation
Text line, fi xed data + 2:nd variable
