X – Draw Box
This command is used to draw a box shape.
Description
Syntax
Xp
1
Parameters p
1
p
2
p
3
p
4
p
5
Example
N↵
X50,200,5,400,20↵
X200,50,10,20,400↵
P1↵
Intermec EasyCoder ESim v4.00—Programmer's Reference Manual
,p ,p ,p ,p
2 3 4 5
Horizontal start position (X) in dots.
Vertical start position (Y) in dots.
Line thickness in dots.
Horizontal end position (X) in dots.
Vertical end position (X) in dots.
Chapter 7—Commands
:Clears image buffer
:Prints box A
:Prints box B
:Prints a label
Box A
Box B
