Status Tools
Diagnostic Tool
System Status screen
Displays system status information,
including auto-answer point to point,
remote control battery, time server,
Global Directory, IP network,
gatekeeper, and ISDN BRI line.
Call Summary screen
Displays calling information, such
as time spent in calls, total number
of IP and ISDN calls, and
percentage of time spent in IP and
ISDN calls.
Call Status screen
Displays call type, data speed, and
number dialed for the current call.
In ISDN calls, this screen also
displays connection status for each
channel. Selecting a channel call
progress indicator displays its ISDN
number.
Call Statistics screen
Displays call speed, audio and
video protocols, annexes, and error
count for the call in progress.
Content Statistics screen
Displays content format, data rate,
frame rate, and packet loss for the
call in progress. Also provides
information about the far site
systems.
Call Detail Report screen
Displays the current Call Detail
Report (CDR) and provides access
to the archived CDR.
The following diagnostic screens and tools are available.
In the system's user interface
On the Diagnostics screen, select
System Status.
1. On the Diagnostics screen,
select System Status.
2. Select
Summary screen.
For more information about this screen, see
On the Diagnostics screen, select
Call Statistics.
For more information about this
screen, see Call Status
For more information about this screen, see
1. On the Diagnostics screen,
select Call Statistics.
2. Select
Statistics screen.
For more information about this screen, see
1. On the Diagnostics screen,
select Call Statistics.
2. Select
the Content Statistics screen.
Not available.
For more information about this screen, see
page 6-4.
In the V500 web interface
Select Diagnostics > System
Status.
Select Diagnostics > System
Status > Call Summary.
to go to the Call
Not available.
on page 6-2.
Select Diagnostics > Call
Statistics.
to go to the Call
Not available.
three times to go to
Select Utilities > Call Detail
Report.
Diagnostics and General Troubleshooting
Call Summary on page 6-1.
Call Status on page 6-2.
Call Statistics on page 6-2.
Call Detail Report (CDR) on
7 - 3
