Chapter 2
•
Compact Flash Socket
Provides Compact Flash socket (Type I or II)
♦
Attached to Primary IDE bus
♦
•
Ethernet
Supports IEEE 802.3 10BaseTX/100Base/1000BaseT compatible physical layer
♦
Supports Auto-negotiation for speed, duplex mode, and flow control
♦
Supports full-duplex or half-duplex mode
♦
• Full-duplex mode supports transmit and receive frames simultaneously
• Supports IEEE 802.3x Flow control in full-duplex mode
• Half-duplex mode supports enhanced proprietary collision reduction mode
•
Utility Interface
Supports standard external 8
♦
Supports external Reset switch
♦
Supports external Power button
♦
•
USB Ports
Provide three root USB hubs
♦
Provide seven USB ports
♦
Support USB v2.0 EHCI and v1.1 UHCI
♦
•
Video (LCD/CRT) Display
Supports full hardware acceleration of H.264 video decode standard
♦
Supports CRT (2048 x 1536) with up to 224MB UMA (Unified Memory Architecture)
♦
Single channel 24-bit LVDS
♦
•
Miscellaneous
Provides Real Time Clock and CMOS RAM, with support for battery-free operation
♦
Provides General Purpose I/O (GPIO) interface
♦
Supports customizable Splash Screen
♦
Supports Watchdog Timer (WDT)
♦
CoreModule 730
"Beep" speaker interface
Ω
Reference Manual
Product Overview
5
