Table 3-3. I/O Address Map (Continued)
03B0-03BB
03C0-03DF
03E8-03EF*
03F6
03F8-03FF*
04D0-04D1
0778-077F*
0CF8-0CFF
0CF9
* Located on the optional expansion module.

USB Interfaces

The CoreModule 730 contains three root USB (Universal Serial Bus) hubs and seven functional USB ports.
The SCH terminates four USB ports to two headers and routes three USB ports to the SUMIT Connector A.
Each of these ports include the following features:
•
USB EHCI v.2.0 and USB UHCI v.1.1
•
Over-current detection
•
Over-current protection
•
High-speed data transfers up to 480 MB/sec on USB 2.0
Table 3-4 describes the pin signals of the USB0 and USB1 header which consists of 10 right-angle pins, in
two rows, with odd/even (1, 2) pin sequence, and 0.079" (2mm) pitch.

Table 3-4. USB0 and USB1 Interface Pin Signals (J12)

Pin # Signal
1 USB-PWR_0
2 USB-PWR_1
3 CONN_USB0_N
4 CONN_USB1_N
5 CONN_USB0_P
6 CONN_USB1_P
7 USB_GND0
8 USB_GND1
9 USB_GND0
10 USB_GND1
Note: The shaded areas denote power or ground.
CoreModule 730
Video (monochrome)
Video (VGA)
Serial Port 3 (COM3)
IDE Hard Disk Controller
Serial Port 1 (COM1)
Edge/Level Trigger PIC
Parallel Port (ECP Extensions) (Port 378+400)
PC I Configuration Registers
Reset Control Register
Description
USB0 Power – VCC (+5V +/-5%) power goes to the port through an on
board fuse. Port is disabled if this input is low.
USB1 Power – VCC (+5V +/-5%) power goes to the port through an on
board fuse. Port is disabled if this input is low.
USB0 Port Data Negative
USB1 Port Data Negative
USB0 Port Data Positive
USB1 Port Data Positive
USB0 Ground
USB1 Ground
USB0 Ground
USB1 Ground
