Chapter 3

Memory Map

The following table provides the common PC/AT memory allocations. These are DOS-level addresses. The
OS typically hides these physical addresses by way of memory management. Memory below 000500h is
used by the BIOS.

Table 3-2. Memory Map

Base Address
00000000h -
000A0000h -
000B0000h -
000B8000h -
000C0000h -
000D0000h -
000E0000h -
000F0000h -
Top 0, 1, 4, or 8MB of DRAM
FFE00000h -
CoreModule 730
Function
0009FFFFh Conventional Memory
000AFFFFh Graphics Memory
000B7FFFh Mono Text Memory
000BFFFFh Color Text Memory
000CFFFFh Standard Video BIOS
000DFFFFh Reserved for Extended BIOS
000EFFFFh Extended System BIOS Area
000FFFFFh System BIOS Area (Storage and RAM Shadowing)
Integrated Graphics Memory
FFFFFFFFh System Flash
