Video Interfaces; Vga Interface; Table 3-7. Vga Interface Pin Signals (J7) - ADLINK Technology CoreModule 730 Reference Manual

Chapter 3
Table 3-6. Ethernet Interface Pin/Signal Descriptions (J3) (Continued)
5 MDI1+
6 MDI1-
7 MDI2+
8 MDI2-
9 MDI3+
10 MDI3-
Note: The shaded areas denote power or ground.
NOTE The magnetics (isolation transformer, T1) for the Ethernet connector is included
on the CoreModule 730.

Video Interfaces

The SCH chip provides the graphics control and video signals to traditional glass CRT (VGA) monitors and
LVDS flat panel displays, supporting full hardware acceleration of H.264 video decode. Other chip features
are listed below:
VGA features:
•
Support for an integrated 400-MHz, 24-bit RAMDAC to drive a progressive scan analog monitor and
outputs to three, 8-bit DACs that provide the R, G, and B signals to the monitor
•
Support for resolutions up to QXGA (2048x1536)
•
Support for a maximum allowable video frame buffer size of 224MB UMA (Unified Memory
Architecture)
LVDS features:
•
Support for a single channel LFP Transmitter interface
•
Support for LVDS LCD panel resolutions up to UXGA (1600X1200)
•
Support for a maximum pixel format of 24 bpp with SSC supported frequency range from 25 MHz to
112 MHz (single channel)

VGA Interface

Table 3-7 describes the pin signals of the VGA interface, which uses 12 right-angle pins, 2 rows, odd/even
sequence (1, 2) with 0.079" (2mm) pitch.

Table 3-7. VGA Interface Pin Signals (J7)

Pin # Signal
1 RED
2 GND1
3 GREEN
4 GND2
5 BLUE
6 GND3
7 HSYNC
8 GND4
CoreModule 730
Media Dependent Interface 1 +/-
Media Dependent Interface 2 +/-
Media Dependent Interface 3 +/-
Description
Red – This is the Red analog output signal to the CRT.
Ground 1 (Red Return)
Green – This is the Green analog output signal to the CRT.
Ground 2 (Green Return)
Blue – This is the Blue analog output signal to the CRT.
Ground 3 (Blue Return)
Horizontal Sync – This signal is used for the digital horizontal sync
output to the CRT.
Ground 4 (VGA)
Reference Manual
Hardware
21
