MWI Code Off - The code Emerald ICE Flash Voice Mail System sends when a
mailbox user has checked all new messages. This code when sent tells the PBX to
deactivate the MWI indicator for that mailbox's extension telephone. When entering
the code, the character ":" represents the extension number. For example, if your
MWI Code Off is L**96 followed by the extension number, enter the following
sequence: L**96: It is recommended to always end the sequence with a comma (1
second pause) to allow the PBX enough time to accept the command before releasing
the port.
MWI/Outdial Port Control - This field tells Emerald ICE Flash Voice Mail System
which ports are allowed to make out dials. There are eight positions corresponding
to ports 1 through 8 - going from left to right. The default value is 00000003. This
default value tells Emerald ICE Flash Voice Mail System to use port 4 to make all
MWI notification and out dial calls.
There are three values that may be entered for any of the port entries:
Mail Box Length - This field tells Emerald ICE Flash Voice Mail System how many
digits are required for the mailbox numbers used in the system. For example – enter
3 if your PBX extension numbers use three digits. A maximum of 4 and a minimum
of 2 digits can be used.
Transfer Sequence - This is the dialing pattern Emerald ICE Flash Voice Mail System
will use to transfer a caller from the Auto Attendant to a mailbox user's telephone.
Default is L&, .
Internal Call Prefix - This is what Emerald ICE Flash Voice Mail System will dial to
access internal dial tone from the PBX. The field will normally be blank since most
PBX systems supply dial tone when the port is taken off-hook to dial.
Reconnect Sequence - This is the dialing pattern Emerald ICE Flash Voice Mail
System will use to reconnect to a caller when there is no answer at the called
telephone extension. Default is L&, .
Minimum On-Hook Delay - This is the period of time that a port will wait after
hanging up before attempting to use that port for an out dial operation. This
prevents collisions when a new call appears at the port right after it has released a
previous caller. If no new incoming call is detected before this timer expires, the out
dial request will be processed.
Out dial Call Prefix - This is the dialing pattern used to tell the PBX an outside line is
needed, such as during an out dial operation. The default value is L9,. If your trunk
access code is different, change this value as required.
5-32
ICE Voice Mail Card Installation & Maintenance Manual
0 – Activates/Deactivates message indicator lights.
1 - MWI indicator calls only will be made from this port.
2 - Out dial calls only will be made from this port.
3 - BOTH MWI indicator and Out dial calls will be made from this port.
