1. Remove the 4 mounting screws from the CCB card and replace with the 4
2. While holding the card close to the Emerald ICE cabinet connect the ribbon cable
3. Line up the 4 mounting holes on Emerald ICE Flash Voice Mail System card wih
4. Turn the Emerald ICE cabinet power on and verify that the Voice Mail card
5. Connect a 9-pin serial cable male-end to the female receptacle on the Emerald
6. Connect the other end of the serial cable with the desired serial port on a laptop
The Emerald ICE Flash Voice Mail System is now installed, synchronized and ready
for programming on a laptop or PC.
4-4
ICE Voice Mail Card Installation & Maintenance Manual
standoffs supplied with the Emerald ICE Flash Voice Mail System card. Set the 4
mounting screws aside.
with the receptacle on the CCB card and connect the red/white power line
connector with the receptacle on the 610-2 board.
the 4 standoffs on the CCB card. Firmly, secure the Emerald ICE Flash Voice Mail
System to the CCB card with the 4 mounting screws previously set aside.
green System Status LED's at the top of the card are alternately blinking.
ICE Flash Voice Mail System card.
or PC.
