Printing Labels; Attendant Console Status Lights - 3Com VCX Manual

assignments on the Console. Press the Shift button to switch between assignments 1 through 50
and assignments 51 through 100. The Shift button LED is lighted when you have buttons 51
through 100 selected.

Printing Labels

download it to your system.
start the LabelMaker program.
existing text, and then typing new text.
dialog. Specify which page you want to print. Typically, the default is to print all pages.
LabelMaker screen. Or you can click File > Save As to save the LabelMaker to a new location.

Attendant Console Status Lights

The first five buttons from the top in the left column correspond to Access buttons 1
through 5. (The bottom four buttons are always the Feature buttons.)
The second column of nine buttons correspond to Access buttons 6 through 14.
The third column of nine buttons correspond to Access buttons 15 through 23.
The fourth column of nine buttons correspond to Access buttons 24 through 32.
The fifth column of nine buttons correspond to Access buttons 33 through 41.
The sixth column of nine buttons correspond to Access buttons 42 through 50.
9) Shift button — Enables you to toggle between the two sets of Access button
To create, print, and save labels for your Attendant Console (or any VCX telephone):
1) Open a browser and navigate to:
http://csoweb4.3com.com/VCX/vcx_doc.cfm
2) Locate the LabelMaker program in the VCX Documentation section, and
3) Locate the LabelMaker .exe file on your system and double-click the file icon to
4) Find the page in the LabelMaker that has labels for your attendant console.
5) Edit the label template by clicking any of the label text boxes to highlight the
6) Press Tab to move to the next text field in the label.
7) Click the Print button at the top of the LabelMaker screen to open the Print
8) Click Print.
9) Cut out the labels and put them in the label holders of your attendant console.
10) To save the edited LabelMaker, click the Save button at the top of the
To reuse your saved LabelMaker, run the file that you saved to your computer. If you
download the LabelMaker from the 3Com web site, you always get the default version.
If you save the default version to the same place you saved an earlier edited version,
you overwrite the earlier version.
An Access button that is set up for incoming and outgoing calls is called a System
Appearance button. The light beside each System Appearance button indicates its
status. See Table 4.
Table 4 Status Indicator Lights for System Appearance Buttons
If the light is
Off
The line is
Available
