Appendix
Technical specifications
RF frequency band
Channels
Operating temperature
Telephone base voltage
(AC voltage, 60Hz)
Telephone base voltage
(AC adapter output)
Handset battery
Charger voltage
(AC adapter output)
Operation
Talk time (cordless handset)
Talk time (cordless handset speakerphone)
Standby
* Operating times vary depending on your actual use and the age of the battery.
DECT 6.0 digital technology
The AT&T DECT 6.0 products offer unsurpassed range performance and sound clarity. This is
achieved through a unique antenna design and advances in noise-filtering technology. An
independent laboratory has confirmed that AT&T DECT 6.0 products perform up to 45% better in
range competitions against similarly equipped phones of the leading competition. Now calls can
be taken in the basement, backyard and garage with exceptional sound quality.
Telephone operating range
This cordless telephone operates within the maximum power allowed by the Federal
Communications Commission (FCC). Even so, this handset and telephone base can communicate
over a certain distance — which can vary with the locations of the telephone base and handset,
the weather, and the construction of your home or office.
Redefining long range coverage and clarity
This telephone base comes with an antenna which gives much better clarity and covers a longer
range than before.
HD audio
HD audio improves sound quality by expanding and rebuilding frequencies that are lost with
traditional phone calls. There is no additional telephone service requirement to use HD audio.
It is designed to work with standard telephone service. Your system will automatically enhance
all received sound with HD audio.
Simulated full-duplex handset speakerphone
The simulated full-duplex speakerphone on your handset allows both ends of a call to speak and
be heard at the same time. Optimal performance is subject to external factors and individual usage.
1921.536MHz - 1928.448MHz
5
32°F - 122°F
0°C - 50°C
96Vrms - 130Vrms
6VDC @ 400mA
2.4V 400mAh, 2xAAA Ni-MH
6VAC @ 300mA
Operating time*
Up to 7 hours
Up to 5 hours
Up to 7 days
108
- Quick Links:
- Delete Call Block Entry
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the CL82114 and is the answer not in the manual?
Questions and answers
What to do when blocked calls cannot be added to. How to make more room for more blocking
To add a blocked call on the AT&T CL82114:
1. Press MENU/SELECT on the handset when it is not in use.
2. Use qCID or pDIR to scroll to Call block, then press MENU/SELECT.
3. Press MENU/SELECT to choose Block list.
4. Use qCID or pDIR to scroll to Add new entry, then press MENU/SELECT.
5. When the screen displays ENTER NUMBER, use the dialing keys to enter the number.
The system can store up to 20 blocked numbers. To make room for additional blocks, you must delete existing entries by accessing the Block list and removing unwanted numbers.
This answer is automatically generated
