D General
• Frequency coverage :
Version TX
EUR
144–146, 430–440
U.K.
144–146,
ITA
430–434, 435–438
FRA 144–146, 430–440
1
* Guaranteed 144–146 MHz and 430–440 MHz only, *
• Mode : FM, FN-N, AM
• No. of memory channels : 1052
(incl. 50 scan edges and 2 call channels)
• Usable temp. range : –20°C to +60°C
‡
• Tuning steps : 5 , 6.25
25, 30, 50, 100, 125 and 200 kHz
• Frequency stability : ±2.5 ppm
• Power supply : 10.0–16.0 V DC for external DC power,
or specified Icom's battery pack
• Digital transmission speed : 4.8 kbps
• Voice coding speed : 2.4 kbps
• Current drain :
(at 7.4 V DC)
Tx High 144 MHz 1.8 A typical
430 MHz 2.1 A typical
Tx Mid. 144 MHz 1.2 A typical
430 MHz 1.5 A typical
Tx Low 144 MHz 0.6 A typical
430 MHz 0.7 A typical
Tx S-Low 144 MHz 0.4 A typical
430 MHz 0.4 A typical
(unit: MHz)
RX
1
0.495–999.990*
2
0.495–29.995* ,
2 2
50–51* , 76–136.995* ,
144–146, 430–434, 435–438
2
0.495–29.995* ,
2 2
50–52* , 76–136.995* ,
144–146, 430–440
2
Not Guaranteed
, WFM , DV
(Rx only) (Rx only)
‡ ‡ ‡ ‡
, 8.33 , 9 , 10, 12.5, 15 , 20,
(–20°C to +60°C)

SPECIFICATIONS

Rx Rated output 170 mA typical
215 mA typical
Power save 30 mA typical
38 mA typical
(Duty 1:4)
standby 62 mA typical
106 mA typical
: SMA (50 Ω)
• Antenna connector
• Dimensions : 58.4(W)×103(H)×34.2(D) mm
(projections not included)
• Weight : 290 g
(approx.)
D Transmitter
• Modulation system :
FM Variable reactance freq. modulation
DV GMSK reactance freq. modulation
(Digital)
• Output power
(at 7.4 V DC)
(Typical) : High 5.0 W, Mid. 2.5 W, Low 0.5 W,
S-Low 0.1 W
• Max. frequency deviation : ±5.0 kHz
±2.5 kHz
• Spurious emissions : Less than –60 dBc at High/Mid.
Less than –13 dBm at Low/Slow
• Ext. mic. impedance : 2 kΩ
‡
Selectable depending on the operating frequency band.
All stated specifications are subject to change without notice or obligation.
15
(FM)
(DV)
(FM)
(DV)
(FM)
(DV)
(with antenna and BP-217)
(FM wide: approx.)
(FM narrow: approx.)
