Icom IC-E80D Instruction Manual page 15

0 • DTMF KEY [0] • [DTMF](0)
Numeral input and DTMF code: '0'
Push and hold for 1 sec. to select DTMF memory
mode. (p. 143)
VFO/MHz • SCAN KEY [V/MHz] • [SCAN](V/MHz)
DTMF code: 'A'
Push to select the VFO mode. (p. 18)
During the VFO mode operation, push to select
1 MHz and 10 MHz tuning steps. (p. 22)
Push and hold for 1 sec. to enter scan type selec-
tion mode. (pgs. 104, 106, 107)
• Push again to start the scan.
Cancels numeral key input. (p. 23)
During menu screen operation or select memory
write mode, push to return to previous operating
condition. (pgs. 94, 115)
MEMORY/CALL • SELECT MEMORY WRITE KEY
[M/CALL] • [S.MW](M/CALL)
DTMF code: 'B'
Push to select memory mode, call channel and TV
channel. (pgs. 18, 19, 27, 92, 93)
Push and hold for 1 sec. to enter select memory
write mode. (p. 94)
PANEL DESCRIPTION
DR (D-STAR REPEATER) KEY [DR]
DTMF code: 'C'
Push to select the DR mode. (pgs. 19, 53, 54, 56)
During DR mode operation, push to enter the ac-
cess repeater selection.
VOLUME CONTROL (UP) KEY [ ]
DTMF code 'D.'
Adjust audio volume level. (p. 16)
BAND • MODE KEY [BAND] • [MODE](BAND)
DTMF code: ' (indication: E)'
During the VFO mode operation, push to select an
operating frequency band. (pgs. 20, 21)
During memory mode operation, push to enter
memory bank group selection. (p. 96)
Push and hold for 1 sec. to select the operating
mode. (p. 25)
.
• UR KEY [.] • [UR](.)
DTMF code '# (indication: F).'
Inputs MHz digit for frequency input.
During DV mode operation (including the DR
mode operation), push and hold for 1 sec. to enter
the station call sign selection mode. (pgs. 60, 61)
• Rotate [DIAL] to select the call sign.
During other than DV mode operation, pushing
and holding this key enters the station call sign
selection mode with changing the operating
mode to the DV mode.
