Comtech EF Data CDM-710G Installation And Operation Manual page 229

CDM-710G High-Speed Satellite Modem
Remote Control
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier)
Number of N/A 3 bytes
Unread stored
Events
Rx Alpha Rolloff RAR= 1 byte
Rx Buffer Size RBS= 5 bytes
Soft Reboot RBT=1 1 byte
Rx Clock RCI= 2 bytes
Invert
Rx Data Invert RDI= 2 bytes
Description of Arguments
Query
Query Only.
Unit returns the Number of stored Events, which remain Unread, in the
form xxx.
Note: This means unread over the remote control.
Example: NUE=126
Command or Query.
Rx Alpha Rolloff, where:
0 = 20%
1 = 25%
2 = 35%
Example: RAR=0 (which is a Rx Alpha Rolloff of 20%)
Command or Query.
Rx Buffer Size (in milliseconds), where:
s=Defines which interface slot ( 1 or 2 )
xx.x= Rx Buffer Size,
HSSI = 5.0 to 32.0 ms, in 0.1 ms steps
GBEI = N/A
E3T3STS1= .5 TO 64 MS IN.5MS STEPS
Example: RBS=130.0 (selects 30.0 ms on interface 1)
Command Only.
Soft Reboot.
1= Reboot System
Command or Query.
Invert Receive Clock, where:
s=Defines which interface slot ( 1 or 2 )
x=Invert Receive Clock, where:
0=Normal
1=Inverted
Note: Command valid only with HSSI.
Example: RCI = 11 (selects Inverted RX Clock, Slot 1)
Command or Query.
Invert Receive Data, where:
s=Defines which interface slot ( 1 )
x=Invert Receive Data, where:
0=Normal
1=Inverted
Note: Command valid with HSSI or E3T3STS1.
Response to
NUE?
NUE*
NUE#
RAR=
RAR?
RAR*
RAR#
RBS=
RBS?
RBS*
RBS#
RBT=
RBT?
RBT*
RBT#
RCI =
RCI?
RCI *
RCI #
RDI =
RDI?
RDI*
RDI#
A–39
MN-CDM710G
Query
(Instruction
Response to Query
Command Code and
Qualifier)
NUE? NUE=xxx
RAR? RAR=x
RBS?s RBS=sxx.x
(see description of
arguments)
N/A RBT=x
RCI?s RCI =sx
(see description of
arguments)
RDI?sc RDI =sx
(see description of
arguments)
Revision 1
