CDM-710G High-Speed Satellite Modem
Remote Control
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier)
External ERF= 1 byte
Reference
Frequency
Rx Es/No N/A 4 bytes
Enable ESW= 1 byte
Redundancy
Switch Mode
Firmware N/A 1 byte
Revisions
Gigabit GIP= 19 bytes
Management IP
Address and
Subnet
Initialize Events IEP= None
Pointer
Boot Image IMG= 1 byte
Description of Arguments
Query
Command or Query.
External Reference Frequency, where:
0=Internal
1=External 1 MHz
2=External 2 MHz
3=External 5 MHz
4=External 10 MHz
5=External 20 MHz
Example: ERF=0 (External reference not used - uses internal)
Query only.
Unit returns the value of EsNo (when in DVB-S2 mode), between 0 and 16
dB, resolution 0.1 dB.
Returns 99.9 if demod is unlocked.
Example: ESN=12.3 (which is Es/No = 12.3 dB)
For values greater than 22.0 dB, the reply will be: ESN=+022
Command or Query.
Set redundancy mode, where :
0 = Disable
1 = Enable
Example: ESW=1 (Enable redundancy mode)
Query Only.
Query the version information of the system. Where:
i = Bulk Image number (1 or 2)
a = Firmware Image
b = Firmware Revision
c = Firmware Date
Example: FRW?1
Command or Query.
Gigabit Management IP address and subnet mask.
s=Slot 2 Only
i=IP Address
n=Netmask
Command Only.
Resets internal pointer to allow RNE? queries to start at the beginning of
the stored events log.
Command or Query.
Boot image selection, where n is the image number:
1=Image #1
2=Image #2
Example: IMG=1 (Selects Image #1 for booting.)
Response to
ERF=
ERF?
ERF*
ERF#
ESN?
ESN*
ESN#
ESW=
ESW?
ESW*
ESW#
FRW?
FRW*
FRW#
GIP=
GIP#
GIP?
GIP*
IEP=
IEP?
IEP*
IEP#
IMG=
IMG?
IMG*
IMG#
A–37
MN-CDM710G
Query
(Instruction
Response to Query
Command Code and
Qualifier)
ERF? ERF=x
ESN? ESN=xxxx
ESW? ESW=x
FRW?i FRW={CR}Boot:{CR}a,b,
c{CR}Bulki:{CR}a,b,c{CR
}a,b,c...
GIP?s GIP=siii.iii.iii.iii.nn
N/A N/A
IMG? IMG=n
