CDM-710G High-Speed Satellite Modem
Front Panel Operation
6.3.1.5

CONFIG: Int1 (CDI-60 HSSI Interface Only)

Note: The menu branch and submenus depicted in this section are dependent on the presence
of the CDI-60 HSSI Interface card, installable in Interface Slot 1 only.
Intfc1 HSSI:
Tx Rx CTS/RTS
Select Tx, Rx, or CTS/RTS using the
(CONFIG:) Intfc1 HSSI
Intfc1 Tx
Data Clock
Select Data, Clock, or Enable using the
If Intfc1 Tx
Intfc1 Tx Data:
Datarate
Select Datarate or Invert using the
If Intfc1 Tx Data:
Intfc1 Data Rate:
Tx: 032.000000 Mbps
This is a read-only status message that indicates the Data Rate of the transmit MPEG-2 transport
stream. Press
ENTER
If Intfc1 Tx Data:
Intfc1 Tx Data Invert:
Normal Inverted
To control data inversion (added for compatibility with certain older equipment), select Normal
or Inverted using the
If Intfc1 Tx
Intfc1 Tx Clock:
Normal Inverted
To control clock inversion (added for compatibility with certain older equipment), select Normal
or Inverted using the
(
Tx
Enable (
Data is Selected:
Invert (
Datarate is selected:
or to return to the previous menu.
CLEAR
Invert is selected:
(
arrow keys, then press
Clock is Selected:
(
arrow keys, then press
E)
arrow keys, then press
E)
arrow keys, then press
E)
arrow keys, then press
ENTER
E)
.
ENTER
E)
.
ENTER
6–27
Revision 1
MN-CDM710G
.
