CDM-710G High-Speed Satellite Modem
Web Server Interface
Once the valid User Name and Password is accepted, the user will see the CDM-710G High-Speed
Satellite Modem Web Server Interface top-level "splash" page:
This splash page identifies the model in use as either the
CDM-710G (70/140 MHz) or CDM-710GL (L-Band) Satellite
Modem unit. This identification is also provided on each
subsequent page under the Comtech EF Data logo at the left-
hand top side (as shown at right):
While the CDM-710G Web Server Interface is depicted throughout this chapter, the appearance and
function of the CDM-710GL Web Server Interface is, for all purposes, otherwise identical to that of
the CDM-710G Web Server Interface.
7.2.1

Web Server Menu Tree

From the splash page, the user has access to five (5) navigation tabs. The following menu tree
illustrates the options available through this interface:
Home
Home
Contact
Support
Click any tab or hyperlink to continue.
Admin Config Mdm
Access Interface
Remote Modem
Modem Utilities
7–3
Stats
Modem Status
Events & Statistics
Revision 1
MN-CDM710G
Maint
Unit Info
