CDM-710G High-Speed Satellite Modem
Front Panel Operation
If Intfc1 Port1 Rx Buffer:
Intfc1 Port1 Rx Frame:
G.751 (1536 Bits)
Select Frame-Type, Size, or ReCenter using the
The Frame Type and the number of bits in the frame displayed are dependent on the choice
selected under Intfc1 Port1:
when the Port Type is E3. The available Frame Type / (Bits) are as follows:
Selected Port Type (as displayed)
E3
T3
STS1
The minimum buffer size is determined by the the number of bits in the frame and the maximum
buffer size is based upon the integral number of frames that can fit in the buffer memory.
If Intfc1 Port1 Rx Buffer:
Intfc1 Port1 Rx Buffer:
10.0 mSec (0344.064 Bits)
The Rx Buffer is programmed in 0.5 ms steps rounded to the increment closest to an integral
number of bits based upon the Frame Type.
The maximum buffer size is:
61 ms;
G.751
The Rx buffer has a minimum value of 0.5 ms (default). Selecting the minimum value and
programming Rx-CLK for Rx-SAT disables the buffer and sets it to minimum.
Use the arrow keys to select the digit to be edited. Use the
of the digit, then press
If Intfc1 Port1 Rx Buffer:
Intfc1 Port1 Rx Buffer:
(65%) Re-Center
The percentage (65%) indicates the current buffer fill status. To reset the buffer to the midpoint
(50%), select Re-Center using the
Frame-Type is selected:
( E)
Type. In the above example, G.751 (1536 Bits) shows the frame
Size is selected:
44 ms;
G.752
ENTER.
ReCenter is selected:
(E)
arrow keys, then press
6–25
arrow keys, then press
Frame Type (Frame Size, in bits, as displayed)
None - default
G.751 (1536 Bits)
G.753 (2148 Bits)
None - default
G.752 (4760 Bits)
None - default
STS-1 (6480 Bits)
61 ms;
G.753
arrow keys to change the value
.
ENTER
Revision 1
MN-CDM710G
.
ENTER
40 ms.
STS-1
