CDM-710G High-Speed Satellite Modem
Front Panel Operation
(CONFIG:) Alarm Mask:
Intfc1 E3T3STS1 Alarms:
Tx Rx ExtClk
Select Tx, Rx, or ExtClk using the ◄ ► arrow keys, then press
If Intfc1 E3T3STS1 Alarms:
Intfc1 Port1 Tx Alarms:
Tx-Cable Tx-AIS
To configure each as an Alarm or Fault condition or to mask the alarm, select Tx-Cable or
Tx-AIS using the
If Intfc1 Port1 Tx Alarms:
Tx Cable Alarm:
Alarm Fault
Select Alarm, Fault, or Mask using the
selection is Alarm.
If Intfc1 Port1 Tx Alarms:
Tx-AIS Alarm:
Alarm Fault
Tx-AIS Alarm affects the event reporting status upon detection of a Tx AIS condition, and
subsequently the switching logic, when the modem is in a 1:1 redundancy configuration.
Select Alarm, Fault, or Mask using the
is Alarm.
If Intfc1 E3T3STS1 Alarms:
Intfc1 Port1 Rx Alarms:
Rx-AIS Buffer-Slip (
To configure each as an Alarm or Fault condition or to mask the alarm, select Rx-AIS or Buffer-Slip
using the arrow keys, then press
If Intfc1 Port1 Tx Alarms:
Rx-AIS Alarm:
Alarm Fault
This selection affects the event reporting status upon detection of a Rx AIS condition, and
subsequently the switching logic, when the modem is in a 1:1 redundancy configuration.
Select Alarm, Fault, or Mask using the
is Alarm.

Intfc1 (CDI-10-1 Single G.703 Interface Card)

( E)
Tx is selected:
( E)
arrow keys, then press
Tx-Cable is selected:
Mask ( E)
Tx-AIS is selected:
Mask ( E)
arrow keys, then press
Rx is selected:
E)
.
ENTER
Rx-AIS is selected:
Mask ( E)
arrow keys, then press
6–38
ENTER
.
ENTER
arrow keys, then press
ENTER.
ENTER.
Revision 1
MN-CDM710G
.
The default
ENTER.
The default selection
The default selection
