2-5 HDD/FDD Installation

To install HDD (Hard Disk Drive), you may connect the connector of
IDE cable to the primary (IDE1) or secondary (IDE2) connector on board,
and then connect the gray connector to your slave device and the black
connector to your master device. If you install two hard disks, you must
configure the second drive to Slave mode by setting its jumpers
correctly. Please refer to your hard disk documentation for the jumper
settings.
CN2
PS/2 Mouse
(on top)
PS/2 K/B
(underside)
USB0
mPGA478B
(on top)
CN3 Aux ATX
USB1 (underside)
RT1
J4 ATX12V
1 2
3 4 VT8753
RT2
AGP 4X
LPC I/O
Controller
PCI 1
1 4
CD_IN1
1 3 WOL1
PCI 2
AC'97
Codec
AC'97
PCI 3
Codec
16
16
PCI 4
1 1
USB2 USB3
JP11
1
PCI 5
PCI 6
SCR1
CNR
Black connector
ZD1
1
VIA
P4X266
FAN3
1 3
ON DIP
1 2 3 4
SW1
Clock IDE4
Generator
Li
VIA
Battery VT8233
1
1 3
IDE4
JP12
IDE3
FAN4
1 3
HDD/LED IR PWR SMI
JP15 JP16 JP18
30
NJP1
1
1 3 1 3 1 3
SPK RST PWR LED SUS LED
IDE Cable
23
Chapter 2 Hardware Setup
Hard Disk Drive Connector:
Orient the red line on the IDE
ribbon cable to Pin1.
IDE2 IDE1
Pin 1 (to Red Line)
Pin 1 (to Red Line)
IDE3 and IDE4 are for IDE
RAID Arrays only.
IDE3
Gray connector
red line
Blue connector
