1. Once you have returned to the Define Array Menu window (below), you will
see the array(s) you have created. You now may use the menu to select
which previously-defined array will be used as the bootable array.
FastBuild (tm) Utility 1.xx (c) 1995-2000 Promise Technology, Inc.
Array No
* Array 1
Note: * --- Bootable Array
[ ] Up [ ] Down [ESC] Exit [Enter] Select
[Space] Change Boot Drive
2. Use the [°Ù] Up [°ı] Down keys to highlight the array which you want to
from boot.
3. Press the [Space] bar.
4. An* asterisk will appear next to the array number indicating it as bootable.
The system will now recognize this array as the first array seen.
5. The system will then use this bootable array as the (fixed) boot C: drive.
NOTE:
The bootable array must contain your configured operating
system.

5-2.9 Creating a "Hot" Spare Drive for Mirroring Arrays

For automatic rebuilds of a mirroring array, attach an extra "spare" drive to
the FaskTrak100-Lite. Drives that are not assigned to an array and are the
same size or larger than the original will be used for the automatic rebuild.
This is performed in the background under all supported operating systems,
except DOS. At a later time, the system can be turned off and the failed
drive can be physically removed.
[Define Array Menu]
RAID Mode Total Drv
Stripe 2
109
Chapter 5 RAID Controller
Capacity(MB) Status
13044 Functional
