SOLTEK SL-85DRV User Manual page 116

Series SL-85DRV
6. The Windows 2000 Setup screen will appear again saying "Setup will
load support for the following mass storage devices:" The list will include
"Win2000 Promise FastTrak100-Lite controller".
Note:
If you need to specify any additional devices to be installed, do
so at this time. Once all devices are specified, continue to step 7.
7. From the Windows 2000 Setup screen, press the Enter key. Setup will
now load all device files and then continue the Windows 2000 installation.
5-3.1-2 Installing Driver To Existing Windows 2000 System
W A R N I N G :
W A R N I N G :
moving the boot drive containing the existing Windows 2000 operating
system on to the FastTrak100-Lite controller (e.g. IDE3/IDE4). On
mainboard 85DRV, IDE1/0 are for system IDE controller, while IDE3
& IDE4 are for RAID IDE controller.
At booting with Windows 2000 system and your hard drive(s) connected to
IDE1/2, Windows 2000 setup will show a "New Hardware Found" dialog
box. Under Windows 2000, the "PCI RAID Controller" will be displayed.
1. In the dialog box, choose "Driver from disk provided by hardware manu-
facturer " button.
2. In the A: drive, insert the FastTrak100-Lite driver diskette.
3. Type "A:\WIN2000" in the text box. Press "Enter".
4. Choose "Win2000 Promise FastTrak100-Lite Controller" from the list
that appears on screen, then press the "Enter" key.
5. The Windows 2000 setup screen will appear again saying "Setup will
load support for the following mass storage device - Win2000 Promise
FastTrak100-Lite controller. The FastTrak100-Lite driver will now be
copied on to the system and entered into the Windows 2000 driver
database.
6. When the "System Setting Change" dialog box appears, remove the
floppy diskette and click on "Yes" to restart the system. Windows
2000 will then restart for the driver installation to take effect.
Your must first complete installing the driver before
116
