Series SL-85DRV
5-2 Using FASTBUILD
TM
The FastBuild
create and configure the drive array on the Promise FastTrak100-Lite.
In this Section, it is assumed you have already created an array in the
previous Section and now wish to make a change to the array or view
other status .

5-2.1 Viewing FastTrak100-Lite BIOS Screen

When you boot your system with the FastTrak100-Lite Controller en-
abled and drives connected to RAID IDE3 / IDE4, the Promise BIOS
on board will detect the drives attached and show the following screen.
FastTrak100-Lite (tm) BIOS Version1.xx (Build xx)
(c) 1995-2000 Promise Technology, Inc. All Rights Reserved.
Scanning IDE drives .......
If an array exists already, the BIOS will display the following screen
showing the Promise BIOS version and status of the array.
FastTrak100-Lite (tm) BIOS Version1.xx (Build xxxx)
(c) 1995-2000 Promise Technology, Inc. All Rights Reserved.
ID MODE SIZE
1* 2+0 Stripe
Press <Ctrl-F> to enter FastBuild (tm) Utility .......
The array status consists of three possible conditions: Functional, Critical,
Off-line.
Functional - The array is operational.
Critical - A mirroring array contains a drive that has failed or
disconnected. The remaining drive member in the array is functional.
However, the array has temporarily lost its ability to provide fault
tolerance. The user should identify the failed drive through the
FastBuild TM Setup utility, and then replace the problem drive.
Off-line - A striped array having only 1 drive has failed or been disconnected.
When the array condition is "Off-line", the user must replace the failed drive
(s) , then restore data from a backup source.
TM Configuration Utility
Configuration Utility offers several menu choices to
TRACK-MAPPING
16126M
102
STATUS
611/128/32 Functional
