Via Onchip Pci Device - SOLTEK SL-85DRV User Manual

Series SL-85DRV
* Primary
Master / Slave PIO
Secondary
Master / Slave PIO
* Primary
Master / Slave UDMA
Secondary
Master / Slave UDMA

VIA ONCHIP PCI DEVICE

•
When this option is chosen, the following item appears for user's
configuration.
CMOS Setup Utility - Copyright (C) 1984-2001 Award Software
VIA-3058 AC'97 Audio
VIA-3068 MC97 Modem
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
* VIA-3058 AC'97
Audio
* VIA-3068 MC97
Modem
Choose Auto or Mode 0~4. The BIOS will detect the
HDD mode type automatically when you choose
Auto. You need to set to a lower mode than Auto
when your hard disk becomes unstable.
The choices: Auto; Mode 0; Mode 1; Mode 2; Mode
3; Mode 4.
Ultra DMA33/66/100 implementation is possible only
if your IDE hard drive supports it, if the operating
environment includes a DMA drive, and if your sys-
tem software supports Ultra DMA33/66/100. Select
"Auto" to enable BIOS support.
The choices: Auto; Disabled.
VIA OnChip PCI Device
Auto
Disabled
Select "Disabled" to use the on-chip audio capability of
your system. Most of the field do not appear when this
field is "Disabled", for user who wants to use add-on sound
card, this item must be disabled.
This option allows you to decide to enable/disable
the Onchip Modem.
The choices: Auto; Disabled.
72
Item Help
Menu Level
