VIA ONCHIP IDE DEVICE

• When this option is chosen, the following item appears for user's
configuration.
CMOS Setup Utility - Copyright (C) 1984-2001 Award Software
OnChip IDE Channel0
OnChip IDE Channel1
IDE Prefetch Mode
Primary Master PIO
Primary Slave PIO
Secondary Master PIO
Secondary Slave PIO
Primary Master UDMA
Primary Slave UDMA
Secondary Master UDMA
Secondary Slave UDMA
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
* On-Chip IDE channel
* IDE Prefetch Mode The on-board IDE drive supports IDE perfecting for
VIA OnChip IDE Device
Enabled
Enabled
Enabled
Auto
Auto
Auto
Auto
Auto
Auto
Auto
Auto
The chipset contains a PCI IDE interface with
0/1 support from two IDE channels. Select Enabled
to activate the first and/or the second IDE
interface. Select Disabled to inactivate an inter-
face if you install a primary and/or second add-
on IDE interface.
The choices: Enabled; Disabled.
faster drive accesses. If the IDE device doesn't sup-
port perfecting, set this field to Disabled.
The choices: Enabled; Disabled.
71
Chapter 4 BIOS Setup
