85SD-C
2-5 HDD/FDD Installation
• To install HDD (Hard Disk Drive), you may connect the connector of IDE
cable to the primary (IDE1) or secondary (IDE2) connector on board, and
then connect the gray connector to your slave device and the black
connector to your master device. If you install two hard disks, you must
configure the second drive to Slave mode by setting its jumpers correctly.
Please refer to your hard disk documentation for the jumper settings.
AGP4X
1
3
JP14
CD1
1
4
1
3
FAN1
CD2
1
4
AC'97
Codec
3
1
WOL1
CNR
Black connector
mPGA478B
1
Intel RG82845
Clock
Generator
Intel RG82845
PCI 1
FDC1
PCI 2
IDE2
PCI 3
IDE1
PCI 4
82801BA
PCI 5
PCI 6
FWH
ON
DIP
FAN3
16
1
3
SW1
USB1
1 2 3 4 5
1
IDE Cable
Hard Disk Drive Connector:
Orient the red line on the IDE
ribbon cable to Pin1.
1
1
1
red line
Blue connector
20
Gray connector
