Series SL-85DRV

1-1 Mainboard Specifications

1-1.1 CPU Socket

•
CPU Socket 478B on board, supporting Intel
processors in the 478-pin package for :
-- 400MHz System Bus;
-- Hyper pipelined technology;
-- Advanced dynamic execution;
-- Advanced transfer cache;

1-1.2 System Chipsets

•
North Bridge VT8753 (P4X266) plus South Bridge VT8233 to work with
Intel Pentium 4 Processor for managing and arbitrating operations between
all system interfaces:

1-1.3 Memory

3 DDR DIMM 184-pin sockets on board for PC2100/1600 DDR SDRAMs,
supported by 2.5V default voltage (DIMM voltage selectable in BIOS setup):
•
VT8753 directly supporting pseudo-synchronous SDRAM transfer rate
100/133MHz up to 1.5GB unbuffered DDR SDRAMs or 3GB registered
DDR SDRAMs.
•
Installation of mixed sizes of DDR SDRAM modules supported .

1-1.4 AWARD BIOS V6.0

•
Supporting Plug & Play V1.0;
•
Flash Memory for easy upgrade;
•
Supporting BIOS writing protection and Year 2000 compliant;
•
BIOS Setup supported (Please see Chapter 4 BIOS Setup);

1-1.5 Accelerated Graphics Port (AGP) Interface

AGP Controller is embedded on VT8753, supporting:
•
1.5V/4X, 3.3V/2X power mode , AGP voltage selectable in BIOS Setup;
•
2x/ 4x AD and SBA signalling, AGP pipelined split-transection long-
burst transfers up to 1GB/sec.;
•
AGP v2.0 compliant;
® Pentium 4 and Northwood
10
