4-6.2 Standard Cmos Setup - SOLTEK SL-85DRV User Manual

Series SL-85DRV

4-6.2 Standard CMOS Setup

•
Standard CMOS Setup records some basic system hardware configuration
and sets the system clock and error handling. You only need to modify the
configuration values of this option if you want to change your system hard-
ware configuration or when the data stored in the CMOS memory gets lost
or damaged.
Run the STANDARD CMOS SETUP as follows:
1. Choose "STANDARD CMOS SETUP" from the Main Menu and a screen
with a list of options will appear:
CMOS Setup Utility - Copyright (C) 1984 - 2001 Award Software
Date (mm:dd:yy)
Time (hh:mm:ss)
IDE Primary Master
IDE Primary Slave
IDE Secondary Master
IDE Secondary Slave
Drive A
Drive B
Video
Halt On
Base Memory
Extended Memory
Total Memory
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
2. Use one of the arrow keys to move between options and modify the
selected options by using PgUp / PgDn / + / - keys.
3. Press <ESC> to return to the Main Menu when you finish setting up all
items. The following item descriptions are provided as a quick guide to
your setup.
Standard CMOS Features
Wed, Aug 22 2001
9 : 52 : 15
Press Enter 13022 MB
Press Enter None
Press Enter None
Press Enter None
1.44M, 3.5 in.
None
EGA/VGA
All, but Keyboard
640K
65472K
66112K
58
Item Help
Menu Level
Change the date
month, year and
century
