Series SL-85DRV

1-1.9 Hardware Monitor on board

•
Programmable control, status, to provide monitoring and alarm for flex-
ible desktop management of hardware temperatures. Utility Software
is enclosed in Support CD to help display monitoring statuses of:
-- 9 voltages, 2 types of hardware temperatures, 2 Fan speeds;

1-1.10 AC'97 Audio Codec on board

•
AC'97 Audio codec supported by AC97 Link on chip VT8233;

1-1.11 CNR Slot on board

•
CNR Slot on board for Modem Riser card or Audio Riser Card;

1-1.12 Disk RAID (Redundant Array of Independent Disks)

+
On SL-85DRV
•
Promise FastTrak100-Lite RAID controller on board.
•
Supporting striping (RAID 0) and mirroring (RAID 1) Disk Arrays.
•
Supporting Ultra ATA/100 / 66 /33 specification up to 100MB/sec.
•
Two RAID Connectors IDE3 and IDE4 on board, compatible with Ultra
ATA/100/66/33 and EIDE, supporting up to 2 RAID disks.

1-1.13 Voice Diagnostic Technology

On SL-85DRV-X and SL-85SD
•
A Voice Diagnostic Function is incorporated in "Advanced BIOS Fea-
tures" of the "Award BIOS Setup" as "VD-Tech II Function". With this
function enabled in "Advanced BIOS Features", it will voice out the prob-
lems or conflicts whenever user configures the components or boots up
the PC system.
•
The voice can be in Chinese or English, depending on the setting of
Jumper JP18. Changing the setting of JP18 will change the language of
the voice.

1-1.14 Form Factor

•
ATX form factor, ATX spec. version 2.03 compliant, supported by one
Main Power Connector, one +12V Power Connector and one Aux Power
Connector;
•
Mainboard size: 305mm x 245mm;
+
and SL-85DRV -X only.
+
-X only:
12
