SOLTEK SL-85DRV User Manual page 122

Series SL-85DRV
5-3.4-2 Installing Drivers With Existing Windows NT4.0
W A R N I N G :
W A R N I N G :
moving the boot drive containing the existing Windows 2000 operating
system on to the FastTrak100-Lite controller (e.g. IDE3/IDE4). On
mainboard 85DRV, IDE1/0 are for system IDE controller, while IDE3
& IDE4 are for RAID IDE controller.
With your bootable hare drive connected to IDE1/IDE2 and FastTrak100-
Lite enabled by JP12, boot Win NT4.0.
1. Choose "Settings" from the "Start" menu.
2. Choose "Controller Panel" from the "Settings" menu.
3. Double-click on the "SCSI Adapters" icon, which generates the "SCSI
Adapters" dialog box.
4. Choose "Drivers," and then press "Add."
5. In the "Install Drivers" dialog box, press "Have Disk..."
6. When the "Install From Disk" appears, insert into Drive A the "FastTrak100-
Lite Driver" diskette that you have made from support CD:.
7. Type "A:\NT4" in the text box window, then choose "OK."
8. When the "Install Driver" dialog box appears, select " Win NT Promise
FastTrak100-Lite controller" and then press "OK."
9. When the "Select SCSI Adapter Option" dialog box appears, press "Install".
10. After a successful installation, the "SCSI Adapter Setup" box will show
that the "Win NT Promise FastTrak100-Lite (tm) Controller" driver has
been installed.
11. Power off your system.
12. Now you can move the boot drive to the FastTrak100-LiteController.
Your must first complete installing the driver before
122
