Chapter
To Get things ready for Hardware setup !
1. We recommend to install your CPU before any other components.
For detailed installation instructions of processor, you can also refer
to the pamphlet enclosed in your CPU package.
2. Installing a cooling fan with a good heatsink is a must for proper heat
dissipation for your CPU. Get ready an appropriate fan with heatsink
for proper installation. Improper fan and installation will damage your
CPU.
3. In case CPU Vcore, CPU clock or Frequency Ratio is adjustable on
board, please follow the instructions described in the User manual
for proper setup. Incorrect setting will cause damage to your CPU.
The following topics are included in this chapter:
2-1 Pentium 4 CPU Installation
2-2 Pentium 4 CPU Fan Installation
2-3 Memory Installation
2-4 HDD/FDD Installation
2-5 AGP 4X (Accelerated Graphic Port) Installation
2-6 ATX 2.03 Power Supply Installation
2-7 Jumper Settings for Devices on board
2-8 Other Connectors Configuration
2
Hardware Setup
17
Chapter 2 Hardware Setup
