1-1.6 Advanced system Power Management, supporting:

•
ACPI 1.0B compliant (Advanced Configuration and Power Interface);
•
APM V1.2 compliant (Legacy power management);
•
ACPI STR mode (Suspend To RAM) , POS (Power On Suspend) and
STD (Suspend to Disk);
•
PS/2 Keyboard & Mouse power on;
•
Wake On Modem and Wake On LAN;
•
Real time clock (RTC) with date alarm, month alarm, and century field.
•
USB wake-up Function;

1-1.7 Multi-I/O Functions:

•
PCI EIDE Controller, supporting:
-- 2x Ultra ATA100 / 66 / 33 IDE Connectors supporting up to 4 IDE devices;
•
Promise RAID IDE Controller:
-- Supporting other two Ultra ATA-100 / 66/ 33 IDE Connectors up to 2 RAID disks
(on SL-85DRV +
•
Dedicated IR Functions:
-- Third serial port dedicated to IR function either through the two complete
serial ports or the third dedicated port Infrared-IrDA (HPSIR) and ASK
(Amplitude Shift Keyed) IR.
•
Multi-mode parallel Data transfer:
--
Standard mode, ECP and EPP support;
•
Floppy Disk connector:
--
One FDD connector with drive swap support;
•
Universal Serial Bus Transfer Mode:
--
USB V1.1 compliant;
-- 2 built-in USB connectors and two USB Headers (USB2, USB3) which re-
quire two optional USB cables to provide 4 more optional USB ports;
•
PS/2 Keyboard
•
PS/2 Mouse
•
UARTs (Universal Asynchronous Receiver / Transmitter):
--
Two complete Serial Ports (COM1 & COM2) on board;

1-1.8 Expansion Slots

•
Six PCI bus Master slots;
•
One AGP 4x/2X slot;
•
One CNR slot (supporting Modem / Audio Riser only);
•
Three DDR DIMM slots;
and SL-85DRV + -X only)
