kozy heat 56701 Installation And Operation Manual
  1. Manuals
  2. Brands
  3. kozy heat Manuals
  4. Indoor Fireplace
  5. 56701
  6. Installation and operation manual
kozy heat 56701 Installation And Operation Manual

kozy heat 56701 Installation And Operation Manual

Direct vent fireplace
Hide thumbs Also See for 56701:
Table of Contents

Advertisement

Quick Links

See also: Installation Manual
DIRECT VENT FIREPLACE
This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home, where not prohibited by
local codes.
A manufactured home (USA only) or mobile home OEM installation must conform with the Manufactured Home Construction
and Safety Standard, Title 24 CFR, Part 3280, or when such a standard is not applicable, the Standard for Manufactured Home
Installations, ANSI/NCSBCS A225.1, or Standard for Gas Equipped Recreational Vehicles and Mobile Housing, CSA Z240.4
WARNING: If the information in these instructions are not followed exactly, a fire or explosion may
result, causing property damage, personal injury or loss of life.
◙
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
IF YOU SMELL GAS:
◙ Do not light any appliance.
◙ Do not touch any electrical switch: do not use any phone in your building.
◙ Immediately call gas supplier from a neighbors phone. Follow the gas supplier instructions.
◙ If you cannot reach your gas supplier, call the fire department.
◙ Installation and service must be performed by a qualified installer, service agency or the gas supplier.
This appliance is only for use with the type (s) of gas indicated on the rating plate.
A conversion kit is supplied with the appliance.
Report No. 216-S-05-5
WARNING
HOT GLASS WILL CAUSE BURNS.
DO NOT TOUCH GLASS UNTIL COOLED.
NEVER ALLOW CHILDREN TO TOUCH GLASS.
www.kozyheat.com
INSTALLATION AND OPERATION MANUAL
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
FEBRUARY 2011-REV-15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 56701 and is the answer not in the manual?

Questions and answers

Connie
June 15, 2025

How do you relight the pilot that has gone out on a Kozy Heat 56701. Tried cleaning it, turning it off, pushing in reset button nothing works.

0
1 comments:
Mr. Anderson
August 19, 2025

To relight the pilot on a Kozy Heat 56701:

1. Turn off all electrical power to the appliance.
2. Open the lower grill to access the gas valve and controls.
3. Push the control knob in slightly and turn it clockwise to the OFF position. Wait 5 minutes to clear any gas.
4. Locate the pilot inside the combustion chamber.
5. Push the control knob in slightly and turn it counterclockwise to PILOT.
6. While holding the knob fully in, push the piezo ignitor button until the pilot lights (usually within 2–3 pushes).
7. Keep holding the knob in for about 1 minute after the pilot lights, then release. The knob should pop out and the pilot should stay lit.
8. If the pilot goes out, repeat steps 3–7.
9. If the pilot still will not stay lit, turn the knob to OFF and contact a service technician or gas supplier.
10. To proceed to burner operation, push the knob in slightly and turn it counterclockwise to ON.

This answer is automatically generated

0

Related Manuals for kozy heat 56701

Summary of Contents for kozy heat 56701

  • Page 1 INSTALLATION AND OPERATION MANUAL INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE. CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE. DIRECT VENT FIREPLACE This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home, where not prohibited by local codes. A manufactured home (USA only) or mobile home OEM installation must conform with the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, or when such a standard is not applicable, the Standard for Manufactured Home Installations, ANSI/NCSBCS A225.1, or Standard for Gas Equipped Recreational Vehicles and Mobile Housing, CSA Z240.4...
  • Page 3 Please retain this owner‟s manual for future reference. CONGRATULATIONS! We welcome you as a new owner of a Kozy Heat gas fireplace. Kozy Heat products are designed with superior components and materials and assembled by trained craftsmen who take pride in their work. The burner and valve assembly are 100% test-fired and the complete fireplace is thoroughly inspected before packaging to ensure that you receive a quality product.

  • Page 5: Table Of Contents

    TMT-028 (56701 only) Optional Fan Installation Burner Tube Adjustment / Troubleshooting GAS LINE CONNECTION Restrictor Troubleshooting / Installation after Termination Completion Gas Line Connection MAINTENANCE 56701 THERMOSTAT / WALL SWITCH / REMOTE Maintenance 56701 Thermostat / Wall Switch / Remote TROUBLESHOOTING VENTING 56701 Troubleshooting...

  • Page 6: Safety Information

    SAFETY INFORMATION This fireplace has been tested to and complies with ANSI Z21.88a-2007·CSA 2.33a-2007·CSA P.4.1-02 “VENTED GAS FIREPLACE HEATERS” by OMNI-Test Laboratories, Portland, OR. Installation must conform with local building codes or in the absence of local building codes, with the National Fuel Gas Code, ANSIZ223.1/NFPA 54 - Current Edition, or the Natural or Propane Installation Code, CSAB149.1 Installation and repair should be done only by a qualified service person.

  • Page 7: Features

    Quick latch glass frame assembly Standing pilot ignition** Upper grill / hood & lower grill (black) Intermittent or Standing pilot ignition* Accepts rigid pipe or Kozy Heat flexible vent system 30-second delay pilot** Patented log design Automatic pressure relief glass system...

  • Page 8: Commonwealth Of Massachusetts Information

    COMMONWEALTH OF MASSACHUSETTS REQUIREMENTS NOTE: The following requirements reference various Massachusetts and national codes not contained in this manual. For all sidewall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied: INSTALLATION OF CARBON MONOXIDE DETECTORS...

  • Page 9: Specifications

    SPECIFICATIONS FIREPLACE DIMENSIONS LETTER KEY DESCRIPTION Height Width Back Width Depth Opening Glass Frame Stand-off Top to Upper Unit Top to Rear Vent Floor to Rear Width Height Height Vent Center Back Vent Center to Top Vent Center INCHES 34-1/2 40-3/4 22-1/2 15-3/4...

  • Page 10: Components List

    SPECIFICATIONS #56701 COMPONENTS LIST #56701-IPI COMPONENTS LIST PART NUMBER DESCRIPTION PART NUMBER DESCRIPTION TRF-770 Millivolt Board Assembly TRF-600-IPI Control Board Assembly 700-203 Manual Gas Shut-off Valve 700-203 Manual Gas Shut-off Valve TRF-030 Burner Cover TRF-030 Burner Cover TRF-035 Burner Tube...

  • Page 11: Prepare The Fireplace

    PREPARE THE FIREPLACE NAILING FLANGE ASSEMBLY & INSTALLATION When installed, nailing flanges provide the minimum 1/4” (6 mm) clearance from fireplace sides. Remove (4) nailing flanges from fireplace sides. With the 1/4” (6 mm) stand-offs on nailing flanges facing away from fireplace, align nailing flange with holes on outside corners of fireplace.

  • Page 12: Framing

    FRAMING WALL ENCLOSURE ROUGH OPENING IMPORTANT: Framing dimensions should allow for wall covering thickness and fireplace facing materials. If using a hearth, adjust rough opening size as necessary to maintain at least minimum clearance requirements. IMPORTANT: NON-COMBUSTIBLE FACING MATERIAL MAY BE APPLIED OVER (BUT NOT DIRECTLY TO) FIREPLACE FACE. THIS WILL PREVENT FACING MATERIAL FROM FALLING OFF DUE TO HEAT EXPANSION.

  • Page 13: Vertical Terminations

    Follow vent pipe manufacturer‟s installation instructions for horizontal terminations. Include required 1-1/2” (38 mm) top clearance and 1” (25 mm) sides and bottom clearances for approved rigid vent systems and the Kozy Heat #700 series flexible vent system. MINIMUM HORIZONTAL FRAMING DIMENSIONS...

  • Page 14: Typical Installation Options

    TYPICAL INSTALLATION OPTIONS REAR VENT VERTICAL TOP VENT 16-1/4” (413 mm) 1” (25 mm) Clearance 27-1/8” (689 mm) 41-1/4” 41-1/4” (1048 mm) (1048 mm) REAR VENT HORIZONTAL 1” (25 mm) Clearance-Sides 1/2” (13 mm) Clearance 1/2” (13 mm) 16-1/4” clearance (413 mm) 41-1/4”...

  • Page 15: Mantel Requirements

    MANTEL REQUIREMENTS NON-COMBUSTIBLE ZONE: Rigid pipe: 1-1/2” (38 mm) above elbow for entire width and depth (behind header) of fireplace. #700 series flexible venting: 1” (25 mm) above elbow for entire width and depth (behind header) of fireplace. 14"(356mm) 12"(305mm) "...

  • Page 16: 56701 Only) Optional Fan Installation

    OPTIONAL FAN INSTALLATION (56701 only) INSTALLATION OF THIS FAN SHOULD BE DONE ONLY BY A QUALIFIED INSTALLER WARNING: MAKE SURE HOUSEHOLD BREAKER IS SHUT OFF PRIOR TO WORKING ON ANY ELECTRICAL LINES. WARNING: THIS APPLIANCE IS EQUIPPED WITH A THREE-PRONG (GROUNDING) PLUG FOR PROTECTION AGAINST SHOCK HAZARD AND SHOULD BE PLUGGED DIRECTLY INTO A PROPERLY GROUNDED THREE-PRONG RECEPTACLE.

  • Page 17: Gas Line Connection

    NOTE: For high altitude installations, consult the local gas distributor or the authority having jurisdiction for proper rating methods. IMPORTANT: The efficiency rating of this appliance is a product of thermal efficiency rating determined under continuous operating conditions and was determined independently of any installed system. 56701 56701-IPI NATURAL GAS LP GAS...

  • Page 18: 56701 Thermostat / Wall Switch / Remote

    THERMOSTAT / WALL SWITCH / REMOTE (56701 only) If desired, a thermostat (wireless style also available), wall switch, or remote control assembly may be used to turn fireplace „OFF‟ and „ON‟. Only ONE of these may be installed. Follow instructions included with chosen assembly.

  • Page 19: Top Vent Conversion Instructions

    VENTING (Top vent conversion instructions) REMOVE BACK VENT COLLARS NOTE: All components removed from fireplace back vent will be re-installed for top venting. Figure 16a Remove back cover and attachment screw . Remove 6-5/8 combustion air intake collar and (4) screws. Remove 4”...

  • Page 20: Top Vent Conversion Instructions

    VENTING (Top vent conversion instructions cont.) INSTALL EXHAUST & COMBUSTION AIR INTAKE COLLARS TO FIREPLACE TOP Tabs Figure 17a Install 4” exhaust collar to fireplace top. Secure with (6) screws previously removed. Install 6-5/8” combustion air intake collar to fireplace top. Secure with (4) screws previously removed. Insert tab on heat shield cover (center previously removed) into slot on fireplace top.

  • Page 21: Approved Venting

    Simpson Dura-Vent DV-GS 4” x 6-5/8” direct vent system (horizontal and vertical terminations). Ameri-Vent Direct Chimney System 4” x 6-5/8” (horizontal and vertical terminations). Kozy Heat #700 series flexible vent system (horizontal terminations). Metal Fab 4” x 6-5/8” direct vent chimney system (horizontal and vertical terminations).

  • Page 22: Horizontal Termination Illustrations

    VENTING NOTE: Horizontal sections require 1/4” (6 mm) rise for every 12” (305 mm) of travel. NOTE: Flange on top stand-off must be bent upwards to a 90˚ angle when top venting. NOTE: Page 22 has information on restrictor installation in conjunction with venting installation. Page 51 has information on restrictor recommendations depending on burner flame appearance and instructions on installation after venting is completed.

  • Page 23: Minimum Venting For Corner Installation

    VENTING HORIZONTAL TERMINATIONS NOTE: Horizontal sections require 1/4” (6 mm) rise for every 12” (305 mm) of travel. NOTE: Flange on top stand-off must be bent upwards to a 90˚ angle when top venting. NOTE: Page 22 has information on restrictor installation in conjunction with venting installation. Page 51 has information on Restrictor recommendations depending on burner flame appearance and instructions on installation after venting is completed.

  • Page 24: Vertical Terminations (Top &Rear Vent)

    ALL RIGID PIPE APPLICATIONS 1 inch (25 mm) 1 inch (25 mm) 1 inch (25 mm) KOZY HEAT #700 SERIES DO NOT USE FOR VERTICAL TERMINATIONS VERTICAL TERMINATIONS (top vent) MAXIMUM: 33 ft. (10.06m) + cap. NOTE: Flange on top stand-off must be bent upwards to a 90˚ angle when top venting.

  • Page 25: Vertical Venting Illustrations

    VENTING MAXIMUM VERTICAL VENTING (top vent) VERTICAL VENTING (rear vent) TERMINATION CAP TERMINATION CAP MIN. 14”(356 mm) MAX. 22 ft (7.71m) MAX. 33 ft.(10.06 m) 90° ELBOW Figure 22a Figure 22b CAUTION: This gas appliance must not be connected to or joined with any other chimney flue serving another appliance. NOTE: Flange on top stand-off must be bent upwards to a 90˚...

  • Page 26: Horizontal / Vertical Combination Venting

    VENTING HORIZONTAL / VERTICAL COMBINATION NOTE: Page 22 has information on restrictor installation in conjunction with venting installation. Page 51 has information on restrictor recommendations depending on burner flame appearance and instructions on installation after venting is completed. Horizontal sections require 1/4” (6 mm) rise for every 12” (305 mm) of travel. Flange on top stand-off must be bent upwards to a 90˚...

  • Page 27: Series Flex Vent Installation

    IF TERMINATING AGAINST VINYL SIDING, A VINYL SIDING PROTECTOR, INCLUDED WITH #718 AND #745 DIRECT VENT KITS, MUST BE USED. FOLLOW INSTRUCTIONS INCLUDED. ATTENTION: Horizontal Top Vent Terminations using Kozy Heat #700 series Flexible Vent System must install # 923-F Kozy Heat Flex Vent System Adaptor.
  • Page 28 VENTING FLEXIBLE #700 SERIES cont. TERMINATION BOX SLOTS IN EXTERIOR WALL PLATE 4” FLEX PIPE COLLAR 4” PIPE ON FIREPLACE OR EXTENSION KIT 7” FLEX PIPE COLLAR 7” PIPE ON FIREPLACE OR EXTENSION KIT VINYL SIDING PROTECTOR INTERIOR FIRESTOP Figure 25a IMPORTANT: If top venting, follow instructions on pages 16-17 to convert fireplace from rear vent ready to top vent ready.

  • Page 29: Termination Cap Location

    TERMINATION VENT CAP LOCATION This gas appliance must not be connected to a chimney serving any other appliance. Terminations against vinyl siding must use a vinyl siding protector. Follow instructions included. DO NOT RECESS TERMINATION KIT INTO OUTSIDE BUILDING MATERIALS - i.e.: brick, stone, siding, etc. If necessary, extend framing so that termination kit will be exposed once building materials are installed.

  • Page 30: Vertical Cap Requirements

    VENTING (Vertical Cap Requirements) VENT TERMINATION CLEARANCES Roof Pitch H (Min.) Ft. H (Min.) m Flat to 6/12 0.30 Over 6/12 to 7/12 1.25 0.38 Over 7/12 to 8/12 0.46 Over 8/12 to 9/12 0.61 Over 9/12 to 10/12 0.76 Over 10/12 to 11/12 3.25 0.99...

  • Page 31: Log Set Installation

    #TRF-500A LOG SET INSTALLATION ATTENTION: If installing optional brick refractory please do so now before installing log set. Follow instructions included with kit. If converting to LP (propane) gas do so now before installing log set. Follow instructions included with kit. NOTE: Log numbers are located on bottom of each log.

  • Page 32: Log Set Installation

    LOG SET INSTALLATION cont. #11, #12 & #6 LOG PLACEMENT Position #11, #12, and #6 logs onto corresponding cut-outs / notches on base logs. The #6 log must not extend over front of #2 log. Figure 29a #7, #8 & #9 LOG PLACEMENT Position #7, #8 and #9 logs onto corresponding cut-outs / notches on base, center logs and log grate.

  • Page 33: Control Board Removal

    CONTROL BOARD REMOVAL CAUTION: If burner and/or pilot have been burning, use appropriate protection to avoid burns or damage to personal property before removing any components. NOTE: Illustrations shown with 56701 valve components. Model 56701 Turn gas control knob to „OFF‟.

  • Page 34: Control Board Installation

    7. Reinstall bottom refractory panels. 8. Reinstall log set. (Page 28-29). 9. Reconnect gas line to manual shut-off valve. 10.Model 56701: Reconnect any wall switch, remote control or thermostat wires to top & bottom terminals on gas valve. Model 56701-IPI: Re-connect all wiring harnesses to gas valve.

  • Page 35: Grill Set

    GRILL SET INSTALLATION Slide flange on upper hood into clips in top of upper air passage Thread screws into nuts on Upper hood each end of grill and secure clips to lower grill opening. Figure 32a Align hooks in upper louver to slots located in fireplace face. Set down into position. Insert upper hood flange into clips located at top of upper air passage, keeping in mind this is a fairly tight fit.

  • Page 36: 56701 Valve And Pilot Assembly Components

    56701 VALVE & PILOT ASSEMBLY COMPONENTS ELECTRODE PILOT HOOD THERMOCOUPLE PILOT SHIELD THERMOPILE HI /LO FLAME ADJUSTMENT KNOB GAS CONTROL KNOB PIEZO IGNITOR VALVE TERMINALS ON/OFF ROCKER SWITCH Figure 33a PAGE 33...

  • Page 37: 56701 Lighting And Shutdown Instructions

    56701 LIGHTING AND SHUTDOWN FOR YOUR SAFETY - READ BEFORE LIGHTING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. DUE TO HIGH SURFACE TEMPERATURES, KEEP CHILDREN, CLOTHING AND FURNITURE AWAY.
  • Page 38 56701 LIGHTING AND SHUTDOWN (cont.) LIGHTING Set thermostat to lowest setting, if installed. 5 MINUTES Turn off all electrical power to appliance. (Fan). Open lower grill to access gas valve & controls. A. Push gas control knob in slightly and turn clockwise to “OFF”.
  • Page 39 56701 LIGHTING AND SHUTDOWN (cont.) TURN BURNER OFF G. To turn burner „OFF‟, depress ON/OFF rocker switch to „OFF‟, flip „off‟ wall switch or adjust setting on thermostat or remote control. NOTE: The pilot will stay lit. TURN PILOT OFF H.

  • Page 40: 56701 Pressure Testing

    56701 PRESSURE TESTING IMPORTANT NOTICE: Pressure check taps for manifold (outgoing) and inlet (incoming) pressure have been incorporated into the valve. The pressure tap marked „OUT‟ measures outgoing pressure and pressure tap marked „IN‟ measures incoming pressure. Follow instructions below for proper testing procedures.

  • Page 41: 56701-Ipi Wiring Schematics

    56701-IPI WIRING SCHEMATICS IMPORTANT: THIS SYSTEM REQUIRES ELECTRICITY (110 V) AND / OR BATTERIES TO OPERATE. USING BATTERY BACK UP WILL OPERATE BURNER ONLY. FAN AND LIGHT COMPONENTS WILL NOT FUNCTION ON BATTERY BACK-UP POWER. Light kit not available in all...

  • Page 42: 56701-Ipi Valve And Pilot Assembly Components

    56701-IPI VALVE & PILOT ASSEMBLY COMPONENTS PILOT IGNITER FLAME SENSOR IPI PILOT ASSEMBLY BLACK CAP OUTLET (MANIFOLD) PRESSURE SCREW PILOT INTERNAL SOLENOID CONNECTION LOW LIMIT SCREW VALVE STEP MOTOR STEP MOTOR WIRE HARNESS PILOT ADJUSTMENT SCREW INLET PRESSURE SCREW MAIN VALVE INTERNAL SOLENOID CONNECTION...

  • Page 43: 56701-Ipi Control Module Components

    56701-IPI CONTROL MODULE COMPONENTS COMMUNICATION LINK TO VALVE STEP MOTOR TERMINAL LEARN BUTTON EXTENSION MODULE AC ADAPTOR CONNECTION MAIN CONTROL MODULE CONTINUOUS PILOT ON/OFF SWITCH REMOTE ON/OFF SWITCH ‟S‟ SENSOR PILOT CONNECTION „I‟ IGNITER PILOT CONNECTION NON-OPERATIONAL BACK-UP BATTERY PACK...

  • Page 44: 56701-Ipi Remote Control Information

    56701-IPI REMOTE CONTROL INFORMATION THERMOSTAT MODE ICON MANUAL ON / OFF ROOM TEMPERATURE BATTERY LIFE ICON SET TEMPERATURE (visible only in THERMO MODE) LIGHT LEVEL FAN SPEED CHILD PROOF ICON CONTINUOUS PILOT FLAME HEIGHT Figure 41a PAGE 41...

  • Page 45: 56701-Ipi Information

    56701-IPI INFORMATION ELECTRICAL WARNING AND INFORMATION: Electrical wiring must be installed by a licensed electrician. Do NOT wire 110V to wall switch. Uninterrupted or continuous power is required at all times in IPI systems EXCEPT when using battery back-up. Incorrect wiring will override IPI safety lockout and may cause an explosion.

  • Page 46: Initial Setup

    56701-IPI REMOTE CONTROL OPERATION INITIAL SET-UP: Plug Extension Module and AC Adaptor into receptacles. Install (4) AAA batteries into battery compartment of Backup Battery Pack , making sure batteries are installed in proper direction. Position between valve and front of stove. A Velcro strip has been attached to help secure in place.
  • Page 47 56701-IPI REMOTE RECEIVER INFORMATION cont. MANUAL MODE: This remote can be manually or thermostatically operated. Press MODE button for manual ON. The flame icon will appear on the LCD screen. Press MODE button again to put the control into THERMO mode.
  • Page 48 56701-IPI REMOTE RECEIVER INFORMATION cont. THERMO (THERMOSTAT) MODE: This remote feature allows you to thermostatically control the fireplace when hand held remote is set to THERMO mode. Set Temperature Range: 45˚F (7˚C) to 90˚F (32˚C). Set remote to THERMO mode by pressing MODE button. The smaller SET window of numbers appears on the LCD screen.

  • Page 49: 56701-Ipi Lighting And Shutdown Instructions

    56701-IPI LIGHTING AND SHUTDOWN FOR YOUR SAFETY - READ BEFORE LIGHTING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. DUE TO HIGH SURFACE TEMPERATURES, KEEP CHILDREN, CLOTHING AND FURNITURE AWAY.
  • Page 50 56701-IPI LIGHTING AND SHUTDOWN (cont.) LIGHTING STOP! Read safety information on previous page and front cover of this manual before continuing. Turn off all electrical power to fireplace. Power OFF ATTENTION: This fireplace is equipped with an ignition device which automatically lights the pilot. DO NOT try to light the pilot by hand.

  • Page 51: 56701-Rf Pressure Testing

    PRESSURE TESTING (56701-IPI) IMPORTANT NOTICE: Pressure check taps for manifold (outgoing) and inlet (incoming) pressure have been incorporated into the valve. The pressure tap marked „OUT‟ measures outgoing pressure and the pressure tap marked „IN‟ measures incoming pressure. Follow instructions below for proper testing procedures.

  • Page 52: 56701-Ipi Error Codes

    ERROR CODES (56701-IPI only) IGNITION SAFETY: Protection for Ignition System Error Code: One beep every one second. Description of Fault: Warns users if pilot is not successfully ignited in 60 seconds. How to Clear: Press MODE button to OFF then to ON to re-attempt ignition.

  • Page 53: Finalizing The Installation

    FINALIZING THE INSTALLATION FLAME APPEARANCE: Flame appearance is affected by several factors including altitude, venting configuration and fuel quality. Although the venturi setting has been factory set, adjustments may be necessary for optimal performance and visual aesthetics. When fireplace is first lit, the flames will be blue. Flames will gradually turn yellowish-orange during first 15 minutes of operation. If flames remain blue, or become dark orange with evidence of sooting (black tips), the burner tube venturi may need adjustment.

  • Page 54: Restrictor Troubleshooting / Installation After Termination Completion

    FINALIZING THE INSTALLATION RESTRICTOR USAGE: Turn fireplace on and allow to burn for 15 minutes. If flames indicate there is excessive draft (flickering, short flames), a restrictor may be necessary. If flames indicate insufficient draft (lifting or ghosting flames), a previously installed restrictor may need to be modified or removed. WARNING: TO AVOID PROPERTY DAMAGE OR PERSONAL INJURY, ALLOW FIREPLACE AMPLE TIME TO COOL BEFORE MAKING ANY ADJUSTMENTS AND / OR INSTALLATIONS.

  • Page 55: Maintenance

    Visually check for blocked port holes, especially near the pilot. Blocked port holes may cause delayed ignition. Reinstall burner assembly following instructions on page 31 of this installation manual. Visually check pilot light and burner when in operation. Flames should be steady, not lifting or floating. Burner Ports 56701 Pilot 56701-IPI Pilot Burner Orifice Figure 52a The fan should be disconnected from electrical current, and cleaned (vacuumed) every six months.

  • Page 56: 56701 Troubleshooting

    TROUBLESHOOTING (56701 only) CAUTION: THE FOLLOWING MUST BE PERFORMED BY A QUALIFIED TECHNICIAN NO SPARK FROM ELECTRODE TO PILOT WHEN PIEZO BUTTON IS TRIGGERED. A. Check wiring at back of piezo for proper connection. B. Check wiring at electrode for proper connection.
  • Page 57 ♦ Free pinched wires if necessary. C Refractory panel placement (if installed). ♦ Refractory panels must be tight against firebox walls. It may be necessary to secure panels with high-temp sealant, especially around intake duct. MORE 56701 TROUBLESHOOTING ON FOLLOWING PAGE PAGE 54...

  • Page 58: Troubleshooting

    TROUBLESHOOTING (56701 only) PILOT AND BURNER EXTINGUISH WHILE IN OPERATION A. No LP (propane) in tank. ♦ Check tank and refill if necessary. B. Glass frame assembly not installed correctly. ♦ Refer to page 12 in this manual for proper glass frame assembly installment instructions.

  • Page 59: 56701-Ipi Troubleshooting

    TROUBLESHOOTING (56701-IPI only) MAIN CONTROL MODULE WILL NOT LEARN TRANSMITTER Ensure REMOTE/OFF switch on side of main control module is set to REMOTE. Make sure batteries in both the hand held remote and backup battery pack are installed in the proper direction and are not drained.

  • Page 60: Troubleshooting

    TROUBLESHOOTING (56701-IPI only cont MAIN FLAME WILL NOT LIGHT Verify gas supply is turned on. Ensure pilot flame will ignite. If not, see pilot flame troubleshooting on previous page. Make sure white cap leads marked MAIN from module are securely connected to terminals marked MAIN on valve body.

  • Page 61: Conversion Kit Instructions (56701 Only)

    CONVERSION KIT INSTRUCTIONS ( 56701 units only) #OCK-S38A NAT GAS CONVERSION KIT / #OCK-S625A LP GAS CONVERSION KIT EQUIPPED WITH SIT GAS VALVE & PILOT ASSEMBLY WARNING: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturers instructions and all applicable codes and requirements of the authority having jurisdiction.

  • Page 62: Conversion Kit Instructions (56701-Ipi Only)

    CONVERSION KIT INSTRUCTIONS ( 56701 units only) COMPLETE THE CONVERSION: Visually check pilot flame. Flame should envelope top of thermocouple and thermopile 3/8” (10 mm) to 1/2” (13 mm), and extend onto burner far enough for proper ignition. To Adjust pilot: Remove pilot adjustment screw from gas valve. Turn inner pilot adjustment screw clockwise to decrease or counter-clockwise to increase pilot flame.

  • Page 63: Conversion Kit Instructions

    CONVERSION KIT INSTRUCTIONS ( 56701-IPI units only) #OCK-A38N-I-TRF-PSE NAT GAS CONVERSION KIT / #OCK-A625L-I-TRF-PSE LP GAS CONVERSION KIT WARNING: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturers instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instructions is not followed exactly, a fire, explosion or production of carbon monoxide may result, causing property damage, personal injury or loss of life.
  • Page 64 CONVERSION KIT INSTRUCTIONS ( 56701-IPI units only) CONVERT GAS CONTROL VALVE: PRESSURE REGULATOR CAP Remove cap covering the pressure regulator. Press down on pressure regulator tube and rotate 90˚. The shaft will pop out and point to chosen gas type. Re-attach cap.

  • Page 65: Replacement Parts List

    This appliance tested & certified by: 204 Industrial Park Drive OMNI - Test Laboratories, Inc. Lakefield, Minnesota 56150 5465 SW Western Avenue 507-662-6641 Beaverton, Oregon 97075 Model #56701 Thief River Falls Model #56701-IPI Thief River Falls - IPI PAGE 62...
  • Page 67 LIMITED WARRANTY PAGE 63...
  • Page 69 LIFETIME WARRANTY PAGE 64...

This manual is also suitable for:

Thief river falls 56701-ipiThief river falls 56701

Table of Contents
