Direct vent gas fireplace
Hide thumbs Also See for 56101 'Windom":
Table of Contents

Advertisement

Quick Links

See also: Operation & Installation Manual
MODEL: #56101 'WINDOM'
DIRECT VENT GAS FIREPLACE
INSTALLATION AND
OPERATING MANUAL
US Patent Number 5,931,154
US Patent Number 6,004,493
Tested &
Beaverton
Listed By
Oregon USA
C
US
OMNI-Test Laboratories, Inc.
READ INSTRUCTIONS CAREFULLY BEFORE INSTALLATION. FAILURE
TO INSTALL THIS FIREPLACE CORRECTLY CAN CAUSE SERIOUS
STRUCTURAL AND FIRE HAZARDS AND MAY VOID YOUR WARRANTY.
www.kozyheat.com
WARNING: If the information in these instructions
is not followed exactly, a fire or explosion may
result, causing property damage, personal injury
or loss of life.
♦ Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS:
♦ Do not try to light any appliance.
♦ Do not touch electrical switches; do not use the
phone in your building.
♦ Immediately call your gas supplier from a
neighbor's phone. Follow your gas supplier's
instructions.
♦ If you cannot reach your gas supplier, call the fire
department.
Installation & service must be performed by a qualified
installer, service agency, or the gas supplier.
This appliance may be installed in an aftermarket
permanently located, manufactured (mobile) home,
where not prohibited by local codes. This appliance is
only for use with the type(s) of gas indicated on the
rating plate. This appliance is not convertible for use
with other gases, unless a certified kit is used.
IMPORTANT:
March 2008
