CDM-800 Gateway Router
Ethernet-based Remote Product Management
Column
UC Pkts Rcvd
MC Pkts Xmitted
MC Pkts Rcvd
Current Xmitted (Kbps)
Current Rcvd (Kbps)
Maximum Xmitted (Kbps)
Maximum Rcvd (Kbps)
Mod Statistics
From left to right:
Column
Pkts Xmitted
UC Pkts Xmitted
MC Pkts Xmitted
Pkts Dropped
UC Pkts Dropped
MC Pkts Dropped
Current (Kbps)
Maximum (Kbps)
Total Bytes Xmitted
Click [Clear All Stats] to delete all existing entries from the Traffic Statistics page.
Description
Unicast packets received.
Multicast packets transmitted.
Multicast packets received.
Most recent transmitted data rate (in kilobits per second).
Most recently received data rate (in kilobits per second).
Peak transmitted data rate (in kilobits per second).
Peak received data rate (in kilobits per second).
Description
Packets transmitted.
Unicast packets transmitted.
Multicast packets transmitted.
Packets dropped.
Unicast packets dropped.
Multicast packets dropped.
Most recent data rate (in kilobits per second).
Peak data rate (in kilobits per second).
Total number of bytes transmitted.
5–35
Revision 1
MN-CDM800
