CDM-800 Gateway Router
Ethernet-based Remote Product Management
•
Description – Enter a label string in this text box. This label helps to maintain the network.
The assigned name must be unique and cannot contain any whitespace.
•
Dest. IP/Mask – Enter a Destination IP Address/Mask in the form XXX.XXX.XXX.XXX/YY.
Multicast addresses must have a subnet of 32.
•
Interf. – Use the drop‐down menu to select the Interface as toWAN or toLAN.
•
Next Hop IP – Enter the desired Next Hop IP Address for toLAN routes. Note that no Next
Hop entry is needed for toWAN routes.
•
WAN Label – This label allows traffic to a defined remote designation to be passed. The
valid label range is from 1 to 2047.
•
•
•
Header Comp. – Use the drop‐down menu to Disable or Enable operations for packets that
match on this route.
•
Payload Comp. – Use the drop‐down menu to Disable or Enable operations for packets that
match on this route.
Enter the desired information. Click [Add Entry] when done. The index automatically increments
to the next available number when the new route is added.
Delete Route
Enter the Route Index to Delete. Click [Delete Entry] when done. This deletes the specified
route entry from the route table.
Route Table (Edit)
Use the text boxes and drop‐down menus to edit all current Route Table entries, as described
previously for the Add New Route section.
Click [Submit Changes] to save these settings.
If the WAN Label does not match any of the WAN Labels defined in the
CDM‐840 Remote Router, and then the packets will be dropped by the
CDM‐840.
The label will be forced to 0 for Multicast addresses. A unique WAN Label for
each remote CDM‐840 is required for correct network operation. If the
remote units have the same WAN Label, then multiple CDM‐840s will receive
the same packet This can cause duplicate packets in the network as well as
unnecessary packet processing, which can reduce the available processing
resources for packets actually destined to a given remote CDM‐840.
5–24
Revision 1
MN-CDM800
