CDM-800 Gateway Router
Ethernet-based Remote Product Management
5.4.4.4
Status Pages
The Status pages provide status, event logging, and operational statistics windows.
Click the Statistics or Monitor tab to continue.
5.4.4.4.1
Status | Statistics Pages
Click the Traffic, Router, Compression, or QoS tab to continue.
5.4.4.4.1.1
Status | Statistics | Traffic
Use this page to view read‐only, abridged status windows pertaining to the basic operational
statistics for the Ethernet, Modulator, and Demodulator traffic.
Ethernet Statistics
From left to right:
Column
Total Pkts Xmitted
Total Pkts Rcvd
UC Pkts Xmitted
Figure 5‐17. Status | Statistics | Traffic page
Description
Total number of packets transmitted.
Total number of packets received.
Unicast packets transmitted.
5–34
Revision 1
MN-CDM800
