CDM-800 Gateway Router
Ethernet-based Remote Product Management
5.4.4.2.6

Admin | VMS

The VMS page is operational only when the optional VIPERSAT MANAGEMENT
SYSTEM (VMS) is installed and operational.
VMS v3.x.x VIPERSAT Management System User Guide (CEFD P/N MN/22156)
Vipersat Management System Configuration
The acceptable/valid operating ranges for items in this section are provided in parentheses.
•
Network ID (1‐255) –The Network ID designation defines to which network the Gateway
Router belongs. All devices in a common network will have the same network ID. The
network ID is used by the VMS to identify Vipersat units within a network and allows the
VMS to manage multiple networks, each with its own unique network ID number.
•
Management Base Port – The Management Base Port sets the starting IP port addressing
for all VMS messages.
Use this setting ONLY if network port addressing is in contention. Changes to this
address base affect the entire network, requiring configuration changes to all
modems.
Leave this setting at default (hex) C000 (des) 49152 to avoid unnecessary
configuration changes.
Figure 5‐8. Admin | VMS page
