CDM-800 Gateway Router
Serial-based Remote Product Management
Start of Packet
<
ASCII code 60
(1 character)
Packet Example:
Start of Packet
>
ASCII code 62
(1 character)
Packet Example:
Detailed description of the packet components follow.
6.2.2.1
Start of Packet
•
Controller‐to‐Target: This is the character '<' (ASCII code 60).
•
Target‐to‐Controller: This is the character '>' (ASCII code 62).
The '<' and '>' characters indicate the start of packet. They may not appear anywhere else within the body of the message.
Controller-to-Target (Issued Command or Query)
Target Address
Address Delimiter
0000 (default)
/
ASCII code 47
(4 characters)
(1 character)
<0000/RSH=30[cr]
Target-to-Controller (Response to Command or Query)
Target Address
Address Delimiter
0000 (default)
/
ASCII code 47
(4 characters)
(1 character)
>0000/BBU=107[cr][lf]
Instruction Code
Code Qualifier
= or ?
ASCII codes 61 or 63
(3 characters)
(1 character)
Instruction Code
Code Qualifier
= or ?
ASCII codes 61 or 63
(3 characters)
(1 character)
6–4
Revision 1
MN-CDM800
Optional Arguments
End of Packet
Carriage Return
ASCII code 13
(n characters)
(1 character)
Optional Arguments
End of Packet
Carriage Return
ASCII code 13
(n characters)
(1 character)
