CDM-800 Gateway Router
Serial-based Remote Product Management
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
GE2 Address IG2= 18 bytes numerical Command or Query.
Management IP IPA= 18 bytes numerical
Address
GE1 Link LC1= 1 byte, value 0 thru
Configuration 5
GE2 Link LC2= 1 byte, value 0 thru
Configuration 5
Description of Arguments
Sets the IP Address and network prefix for the 10/100/1000 BaseT GE2 Ethernet
port, in the form aaa.bbb.ccc.ddd/yy, where:
(Permitted ranges – cannot all be zero)
aaa = 0-223
bbb = 0-255
ccc = 0-255
ddd = 0-255
yy = network prefix (range: 8 to 31)
Other restrictions:
If aaa>191, prefix may not be less than 24.
If aaa>127, prefix may not be less than 16.
Example: IG2=010.006.030.001/24
Command or Query.
Sets the IP Address and network prefix for the 10/100 Base T Ethernet
management port, in the form aaa.bbb.ccc.ddd/yy, where:
(Permitted ranges – cannot all be zero)
aaa = 0-223
bbb = 0-255
ccc = 0-255
ddd = 0-255
yy = network prefix (range: 8 to 31)
Example: IPA=010.006.030.001/24
Command or Query.
GE1 Interface mode, where:
0 = Auto Negotiate
1 = 1000Mbps -Full Duplex
2 = 100Mbps – Full Duplex
3 = 100Mbps – Half Duplex
4 = 10Mbps – Full Duplex
5 = 10Mbps – Half Duplex
Command or Query.
GE2 Interface mode, where:
0 = Auto Negotiate
1 = 1000Mbps -Full Duplex
2 = 100Mbps – Full Duplex
3 = 100Mbps – Half Duplex
4 = 10Mbps – Full Duplex
5 = 10Mbps – Half Duplex
6–10
MN-CDM800
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
IG2= IG2? IG2=xxx.xxx.xxx.xxx/yy
IG2? (see Description of Arguments)
IG2*
IG2#
IPA= IPA? IPA=xxx.xxx.xxx.xxx/yy
IPA? (see Description of Arguments)
IPA*
IPA#
LC1= LC1? LC1=x
LC1? (see Description of Arguments)
LC1*
LC1#
LC2= LC2? LC2=x
LC2? (see Description of Arguments)
LC2*
LC2#
