CDM-800 Gateway Router
Introduction
1.3.3.2.2

Rear Panel Optional Features

The unit provides the following Data Interface for optional hardware operation:
•
(1X) DB‐9M EIA‐232 connector labeled "REDUNDANCY" for interoperability with a
separately purchased Comtech EF Data CRS‐170A 1:1 Redundancy Switch for L‐Band
operation, or the CRS‐180 1:1 Redundancy Switch for 70/140 MHz operation.
M:N device redundancy support is available with the separately purchased Vipersat
Management System (VMS).
The following Power Interface Option is available from Comtech EF Data:
•
48 VDC Primary Input Power Supply with Screw‐in Fuse Holders
The following installation kits are available from Comtech EF Data:
•
KT/6228‐2 4" Rear‐Mounting Support Brackets Kit
•
KT/6228‐3 10" Rear‐Mounting Support Brackets Kit
Sect. 2.2.1 Installing the Optional Rear‐Mounting Support Brackets Kit
1–7
Revision 1
MN-CDM800
